SQL is a declarative, English-like domain language for querying, analyzing, and manipulating data. SQL originated from relational databases but has since seen wide adoption outside of them. Because SQL statements can almost be read as English sentences and its declarative nature, that is, users declare what results they want and not how to get to these results (the latter is the approach of imperative programming languages, such as C, Java, Python, etc), SQL is generally seen as one of the best high-level languages for analyzing data due to its easy-to-learn syntax.
SQL has different language elements that can, at the very top level, be divided between queries and data manipulation. SQL queries use the SELECT statement, while SQL used for data manipulation uses the INSERT, UPDATE, DELETE, and MERGE statements. The latter group of statements for data manipulation is referred to as Data Manipulation Language or DML.
Table of Contents
SQL queries
SQL queries are probably the most common operations used in SQL, as they allow users to retrieve and analyze data from one or more tables. SQL query statements include the following elements:
SELECTFROMJOINWHEREGROUP BYHAVINGORDER BYOFFSETFETCH
The SELECT statement includes a couple of elements, but only the first two are required: SELECT and FROM. However, some databases, including Oracle Database and MySQL, make the FROM clause optional if the SELECT refers only to self-contained expressions, such as SELECT 1; SELECT sysdate; and SELECT my_function();. In these cases, the data is not derived from a table, hence FROM is not required.
Optional components are illustrated by [ ] around them.
SELECT <expressions>
FROM <table or sub-query>
[ JOIN <to other table> ON <join condition> ]
[ WHERE <predicates> ]
[ GROUP BY <expressions>
[ HAVING <predicates> ] ]
[ ORDER BY <expressions> ]
[ OFFSET ]
[ FETCH ]
A common misconception is that these components execute in the same order as they appear in the query. This is not the case, as the SELECT component is processed after the HAVING clause. The following lists the order that which the clauses are processed and their purpose:
| order | clause | purpose |
|---|---|---|
| 1 | FROM | Indicates which table(s) to retrieve data from. The FROM clause determines the working set of data that is being retrieved. This usually refers to a table, but can also include a subquery (another SELECT query that acts as the input source for the current query). |
| 2 | JOIN | Specifies the rules for joining multiple tables. The JOIN clause is part of the FROM clause and combines the data from multiple tables into one dataset. It is one of the fundamental operators of the relational model to combine different relations into one set. The JOIN clause allows join conditions that ensure that only rows that logically belong together are joined (rows with matching primary key –> foreign key relationships). Multiple JOIN clauses can be specified to join multiple tables into the data set. Because the JOIN clause is part of the FROM clause, it cannot be specified without a preceding FROM statement in the query. |
| 3 | WHERE | Filters the rows returned by the query. The WHERE clause filters the data set based on the provided predicates or filter conditions and discards all rows that do not match them. It narrows down the results, for example, to retrieve all countries from the continent of Europe instead of all countries in the world. |
| 4 | GROUP BY | Aggregates (or groups) rows with common values in the specified column(s) into one row. The resulting row is sometimes referred to as a grouping set. Because rows with common values are aggregated into one row, there will only be as many rows as there are unique values. For values of columns not specified in GROUP BY, aggregate functions in the SELECT clause are required to aggregate these values per group. |
| 5 | HAVING | Filters rows resulting from the GROUP BY clause. It is therefore a part of the GROUP BY and cannot be used without a preceding GROUP BY statement in the query. |
| 6 | SELECT | Defines the list of column(s) and expression(s) to appear in the query result output. The SELECT clause computes any expressions and defines the list of columns to be returned, or projected, as the query result. |
| 7 | ORDER BY | Identifies which column(s) to use to sort the resulting data and in which direction to sort them (ascending or descending). If the ORDER BY is omitted, the order of the rows returned by a SQL query is undefined. |
| 8 | OFFSET | Specifies the number of rows to skip in the result set before returning the data. |
| 9 | FETCH | Specifies the number of rows to return from the result. |
Using SQL Queries
Now that you’re familiar with what the various SQL query clauses mean, you can start using them. You can follow along with these exercises using the data model in my GitHub repository.
SELECT and FROM
In its simplest form, a SQL query comprises of a SELECT and FROM clause:
SQL> SELECT *
2* FROM regions;
REGION_ID NAME
____________ ________________
AF Africa
AN Antarctica
AS Asia
EU Europe
NA North America
OC Oceania
SA South America
7 rows selected.
This query selects all rows and all columns (as indicated by the * after the SELECT which is short for “all columns”) from a table called regions. If we wanted to return a given list of columns, these can be called out specifically, for example:
SQL> SELECT name
2* FROM regions;
NAME
________________
Africa
Antarctica
Asia
Europe
North America
Oceania
South America
7 rows selected.
SELECT without FROM
The SELECT statement is also able to compute expressions, for example, 1+2. Technically, neither the constant 1 nor the constant 2 are coming from any table, but the ISO SQL standard nevertheless requires a FROM clause. Many databases have hence provided “dummy” tables to enable such queries, for example, the dual table in Oracle Database.
SQL> SELECT 1+2
2* FROM dual;
1+2
______
3
However, many databases, including Oracle Database, have also loosened this restriction from the SQL standard and allow for queries to omit the FROM clause in such cases:
SQL> SELECT 1+2;
1+2
______
3
JOIN
The relational model is all about normalizing data, that is, putting independent data into separate tables and defining relationships between these tables. To recombine such normalized data, joins are provided to join these tables back together.
The following example has two tables: the previously queried regions table, and the new countries table. To write a query that joins both tables into one result, you use the JOIN clause. Without a JOIN clause, if you specify the two tables in the FROM clause, every row from the table regions will be multiplied by every row from the table countries. This is often referred to as the cross product and it’s a common mistake that SQL beginners make. For example:
SQL> SELECT r.name, c.name
2* FROM regions r, countries c;
NAME NAME
________________ ___________________________________
Africa Kosovo
Africa Yemen
Africa South Africa
Africa Zambia
Africa Zimbabwe
Africa Andorra
Africa United Arab Emirates
Africa Afghanistan
Africa Antigua and Barbuda
Africa Albania
Africa Armenia
Africa Angola
Africa Argentina
Africa Austria
Africa Australia
...
...
...
South America Uzbekistan
South America Vatican City
South America Saint Vincent and the Grenadines
South America Venezuela
South America Vietnam
South America Vanuatu
South America Samoa
1,372 rows selected.
The output from this query is obviously incorrect. There are neither 1,372 countries, nor is Austria located in Africa. What we really want is to join all rows from the countries table with the regions table where the region_id is the same. This is generally referred to as the join condition and can be specified in the ON clause as part of the JOIN clause:
SQL> SELECT r.name, c.name
2 FROM regions r
3 JOIN countries c
4* ON (r.region_id=c.region_id);
NAME NAME
________________ ___________________________________
Africa South Africa
Africa Zambia
Africa Zimbabwe
Africa Angola
Africa Burkina Faso
Africa Burundi
Africa Benin
...
...
...
South America Ecuador
South America Guyana
South America Peru
South America Paraguay
South America Suriname
South America Uruguay
South America Venezuela
196 rows selected.
That’s more like it!
There is one more thing to note: The above queries specified SELECT r.name, c.name and put the letters r and c next to the table names. These are table aliases and are required to tell the database which table column you want. If the statement just said SELECT name, name, it would be unclear whether the query refers to the regions table column name or the countries table column name.
WHERE
The WHERE clause filters the rows produced by the FROM clause. Until now, you have always gotten all the rows that were in the tables. If you want to return only all countries in South America, this is where the WHERE clause comes in. It can be used to match all rows with the regions.name column value 'South America':
SQL> SELECT r.name, c.name
2 FROM regions r
3 JOIN countries c
4 ON (r.region_id=c.region_id)
5* WHERE r.name = 'South America';
NAME NAME
________________ ____________
South America Argentina
South America Bolivia
South America Brazil
South America Chile
South America Colombia
South America Ecuador
South America Guyana
South America Peru
South America Paraguay
South America Suriname
South America Uruguay
South America Venezuela
12 rows selected.
GROUP BY
The GROUP BY clause is often a puzzle for SQL beginners. The clause is used to aggregate multiple rows into a group, essentially combining multiple rows into one row. When would such a thing ever be useful? Well, for example, the countries table contains a column called population, but the regions table does not:
SQL> SELECT r.name, c.name, c.population
2 FROM regions r
3 JOIN countries c
4 ON (r.region_id=c.region_id)
5* WHERE r.name = 'South America';
NAME NAME POPULATION
________________ ____________ _____________
South America Argentina 44694000
South America Bolivia 11306000
South America Brazil 208847000
South America Chile 17925000
South America Colombia 48169000
South America Ecuador 16291000
South America Guyana 741000
South America Peru 31331000
South America Paraguay 7026000
South America Suriname 598000
South America Uruguay 3369000
South America Venezuela 31689000
12 rows selected.
A common business question might be: “What is the total population of each region?” Given that the regions table does not have a column with that information, the answer can be provided only by calculating the sum of the population column for each country per region. So, you need a mechanism that takes the 196 rows of the countries table and puts them into seven groups or buckets based on their region (because there are seven rows in the regions table). However, the query cannot just put the 196 rows into seven rows; it needs to calculate the sum of the population per region based on the populations of the countries belonging to the region.
This can be done by applying the SUM() aggregate function over the population column:
SQL> SELECT r.name, SUM(c.population)
2 FROM regions r
3 JOIN countries c
4 ON (r.region_id=c.region_id)
5* GROUP BY r.name;
NAME SUM(C.POPULATION)
________________ ____________________
Africa 1263685000
Asia 4439011000
Europe 748985000
North America 575767000
Oceania 37556000
South America 421986000
6 rows selected.
This query shows something else interesting. Although there are seven regions in the regions table, the query produced six rows. This is because there is a region 'Antarctica', but there is no country with that region_id in the countries table. Hence, the JOIN clause filters that region out (because there is no matching region_id in the countries table as specified by the ON clause).
A GROUP BY clause does not require any JOIN clause; you can create groups in just a single table. For example, “How many countries start with the same letter?” can also be answered via a GROUP BY. To do this, create as many groups per the unique first letter value for all rows by using the SUBSTR() function, and then count the rows that fall into that group or category:
SQL> SELECT SUBSTR(name,1,1), COUNT(*)
2 FROM countries
3* GROUP BY SUBSTR(name,1,1);
SUBSTR(NAME,1,1) COUNT(*)
___________________ ___________
K 6
Y 1
S 26
Z 2
A 11
U 7
B 17
C 17
D 5
G 11
E 8
F 3
M 18
H 3
I 8
J 3
N 11
L 9
O 1
P 9
Q 1
R 3
T 12
V 4
24 rows selected.
HAVING
The HAVING clause filters rows resulting from the GROUP BY clause based on the predicate(s) provided. For example, if you want to return only the regions that have a population of more than 500 million people, this cannot be specified in the WHERE clause because the WHERE clause is processed before the GROUP BY clause. Hence, the WHERE clause has no notion of the population of a region. This is where the HAVING clause comes in. From a logical perspective, it behaves the same as the WHERE clause, but it filters at a different processing stage:
SQL> SELECT r.name, SUM(c.population)
2 FROM regions r
3 JOIN countries c
4 ON (r.region_id=c.region_id)
5 GROUP BY r.name
6* HAVING SUM(c.population) > (500 * 1000 * 1000);
NAME SUM(C.POPULATION)
________________ ____________________
Africa 1263685000
Asia 4439011000
Europe 748985000
North America 575767000
ORDER BY
The ORDER BY clause sorts the resulting data. So far, the undefined sorting of the rows has worked out, except when it came to “countries per first letter.” The ORDER BY clause can be used to return the rows in alphabetical order:
SQL> SELECT SUBSTR(name,1,1), COUNT(*)
2 FROM countries
3 GROUP BY SUBSTR(name,1,1)
4* ORDER BY SUBSTR(name,1,1);
SUBSTR(NAME,1,1) COUNT(*)
___________________ ___________
A 11
B 17
C 17
D 5
E 8
F 3
G 11
H 3
I 8
J 3
K 6
L 9
M 18
N 11
O 1
P 9
Q 1
R 3
S 26
T 12
U 7
V 4
Y 1
Z 2
24 rows selected.
By default, rows are sorted in ascending order, but you can reverse it with the DESC (DESCENDING) keyword:
SQL> SELECT SUBSTR(name,1,1), COUNT(*)
2 FROM countries
3 GROUP BY SUBSTR(name,1,1)
4* ORDER BY SUBSTR(name,1,1) DESC;
SUBSTR(NAME,1,1) COUNT(*)
___________________ ___________
Z 2
Y 1
V 4
U 7
T 12
S 26
R 3
Q 1
P 9
O 1
N 11
M 18
L 9
K 6
J 3
I 8
H 3
G 11
F 3
E 8
D 5
C 17
B 17
A 11
24 rows selected.
OFFSET
The OFFSET clause specifies the number of rows to skip before starting to return data. This clause is shorthand for what would otherwise require analytic queries or subqueries. For example, asking “Give me all countries in South America ranked by square kilometers except the first three” can be answered with:
SQL> SELECT c.name, c.area_sq_km
2 FROM countries c
3 JOIN regions r
4 ON (c.region_id=r.region_id)
5 WHERE r.name = 'South America'
6 ORDER BY area_sq_km DESC
7* OFFSET 3 ROWS;
NAME AREA_SQ_KM
____________ _____________
Colombia 1138910
Bolivia 1098581
Venezuela 912050
Chile 756102
Paraguay 406752
Ecuador 283561
Guyana 214969
Uruguay 176215
Suriname 163820
9 rows selected.
FETCH
The FETCH clause specifies the number of rows to return from the result. Some databases call this the LIMIT clause. Like the OFFSET clause, this is also a shorthand and can be used to answer business questions like “What are the top three countries in terms of population?” This can be answered with:
SQL> SELECT name, population
2 FROM countries
3 ORDER BY population DESC
4* FETCH FIRST 3 ROWS ONLY;
NAME POPULATION
________________ _____________
China 1384689000
India 1296834000
United States 329256000
You may wonder what would happen if two rows tie in the third position; will both rows be returned? Or just the first? For these cases, the FETCH clause provides the ONLY and WITH TIES keywords. The above just used ONLY because it is unlikely that two countries have the same population.
However, when ranking countries by letter, there is much more room for overlap. For example, in the countries per first letter example, when ranked by number of countries, it is clear that some letters have the same number:
SQL> SELECT SUBSTR(name,1,1), COUNT(*)
2 FROM countries
3 GROUP BY SUBSTR(name,1,1)
4* ORDER BY COUNT(*) DESC;
SUBSTR(NAME,1,1) COUNT(*)
___________________ ___________
S 26
M 18
B 17
C 17
T 12
A 11
N 11
G 11
L 9
P 9
I 8
E 8
U 7
K 6
D 5
V 4
J 3
H 3
F 3
R 3
Z 2
Q 1
Y 1
O 1
24 rows selected.
If you run the same FETCH clause on this query, the letter C would be omitted from the results, although it has exactly the same number of countries as the letter B:
SQL> SELECT SUBSTR(name,1,1), COUNT(*)
2 FROM countries
3 GROUP BY SUBSTR(name,1,1)
4 ORDER BY COUNT(*) DESC
5* FETCH FIRST 3 ROWS ONLY;
SUBSTR(NAME,1,1) COUNT(*)
___________________ ___________
S 26
M 18
B 17
This is where the WITH TIES keyword comes in, as it will include ties in the results:
SQL> SELECT SUBSTR(name,1,1), COUNT(*)
2 FROM countries
3 GROUP BY SUBSTR(name,1,1)
4 ORDER BY COUNT(*) DESC
5* FETCH FIRST 3 ROWS WITH TIES;
SUBSTR(NAME,1,1) COUNT(*)
___________________ ___________
S 26
M 18
B 17
C 17
OFFSET & FETCH
Combining the OFFSET and FETCH clauses allow another nice shorthand that would otherwise require an analytical query or subquery. Consider the question “What is the second smallest country on the planet in terms of square kilometers?” This can be answered by combining OFFSET to return results starting from the second row, and FETCH to fetch just the second row
SQL> SELECT name, area_sq_km
2 FROM countries
3 ORDER BY area_sq_km
4 OFFSET 1 ROW
5* FETCH FIRST 1 ROW ONLY;
NAME AREA_SQ_KM
_________ _____________
Monaco 2
Data Manipulation Language (DML)
The Data Manipulation Language is a set of SQL statements used to add, update, and delete data. SQL used for data manipulation uses INSERT, UPDATE, DELETE and MERGE statements.
| clause | purpose |
|---|---|
INSERT | Inserts data in a table by adding one or more rows to a table. |
UPDATE | Updates one or more rows in a table. |
DELETE | Deletes one or more rows from a table. |
MERGE | Can be used to add (insert) new rows, update existing rows or delete data in a table, depending on whether the specified condition matches. It is a convenient way to execute one operation, where you would otherwise have to execute multiple INSERT or UPDATE statements. |
Using DML
Now that you’re familiar with what the various DML statements mean, you can start using them. You can follow along with these exercises using the data model in my GitHub repository
INSERT INTO
The INSERT INTO statement adds rows to a table. It can be used by either defining one or more rows using the VALUES clause or by inserting the result of a subquery. Take a look at the VALUES clause first:
SQL> -- Creates an empty copy of countries called my_tab
SQL> CREATE TABLE my_tab AS SELECT * FROM countries WHERE rownum=0;
Table MY_TAB created.
SQL> INSERT INTO my_tab (country_id, country_code, name, population, region_id)
2* VALUES (1, 'GV', 'State of Gerald', 1, 'AN');
1 row inserted.
SQL> SELECT * FROM my_tab;
COUNTRY_ID COUNTRY_CODE NAME OFFICIAL_NAME POPULATION AREA_SQ_KM LATITUDE LONGITUDE TIMEZONE REGION_ID
_____________ _______________ __________________ ________________ _____________ _____________ ___________ ____________ ___________ ____________
1 GV State of Gerald 1 AN
The VALUES clause allows multiple rows to be defined by separating them with a comma (,):
SQL> INSERT INTO my_tab (country_id, country_code, name, population, region_id)
2 VALUES (2, 'VX', 'Venzi Country', 1, 'AN'),
3* (3, 'XX', 'Gerald Island', 1, 'AN');
2 rows inserted.
SQL> SELECT * FROM my_tab;
COUNTRY_ID COUNTRY_CODE NAME OFFICIAL_NAME POPULATION AREA_SQ_KM LATITUDE LONGITUDE TIMEZONE REGION_ID
_____________ _______________ __________________ ________________ _____________ _____________ ___________ ____________ ___________ ____________
1 GV State of Gerald 1 AN
2 VX Venzi Country 1 AN
3 XX Gerald Island 1 AN
To use a SQL query as input for the INSERT statement, just replace VALUES with SELECT. The columns of your table and the SELECT list must match:
SQL> INSERT INTO my_tab SELECT * FROM countries;
196 rows inserted.
SQL> SELECT *
2 FROM my_tab
3* FETCH FIRST 5 ROWS ONLY;
COUNTRY_ID COUNTRY_CODE NAME OFFICIAL_NAME POPULATION AREA_SQ_KM LATITUDE LONGITUDE TIMEZONE REGION_ID
_____________ _______________ ___________________________________ ___________________________________ _____________ _____________ ___________ ____________ _____________________ ____________
VAT VA Vatican City Vatican City State 1000 0.44 41.90225 12.4533 Europe/Vatican EU
VCT VC Saint Vincent and the Grenadines 102000 389 13.08333 -61.2 America/St_Vincent NA
VEN VE Venezuela Bolivarian Republic of Venezuela 31689000 912050 8 -66 America/Caracas SA
VNM VN Vietnam Socialist Republic of Vietnam 97040000 331210 16.16667 107.83333 Asia/Ho_Chi_Minh AS
VUT VU Vanuatu Republic of Vanuatu 288000 12189 -16 167 Pacific/Efate OC
Update
The UPDATE statement updates entries in a table. It has a SET clause that sets columns to a given value and a WHERE clause to specify which rows to update. You almost always want a WHERE clause for your UPDATE statement; otherwise, the UPDATE statement will update all rows in the table.
SQL> UPDATE my_tab
2 SET population = 2
3* WHERE country_code = 'GV';
1 row updated.
SQL> SELECT *
2 FROM my_tab
3* WHERE country_code = 'GV';
COUNTRY_ID COUNTRY_CODE NAME OFFICIAL_NAME POPULATION AREA_SQ_KM LATITUDE LONGITUDE TIMEZONE REGION_ID
_____________ _______________ __________________ ________________ _____________ _____________ ___________ ____________ ___________ ____________
1 GV State of Gerald 2 AN
The UPDATE statement can also join other tables to update rows based on a WHERE clause condition outside of the table that is being updated. For example, say you want to adjust the population of all countries in South America by 10% more (an expression formulated as population*1.1). You can filter the rows to update based on a filter via the regions table for the countries that have the appropriate region_id for South America:
SQL> UPDATE countries c
2 SET c.population = c.population*1.1
3 FROM regions r
4 WHERE c.region_id=r.region_id
5* AND r.name = 'South America';
12 rows updated.
DELETE
The DELETE statement deletes rows in a table and works very similarly to the UPDATE statement. As with UPDATE, with the DELETE statement you almost always want a WHERE clause; otherwise, you will delete all rows in a table.
SQL> DELETE FROM my_tab
2* WHERE country_code = 'GV';
1 rows deleted.
Also like the UPDATE statement, you can apply the same filter based on other tables’ column values:
SQL> DELETE FROM my_tab c
2 FROM regions r
3 WHERE r.region_id=c.region_id
4* AND r.name = 'Antarctica';
2 rows deleted.
MERGE
The MERGE statement is more sophisticated than the INSERT, UPDATE and DELETE statements. The MERGE statement allows you to conditionally insert or update (and even delete some) rows with one execution. This is most helpful when you want to load data into tables with existing rows and, for example, do not want to manually check whether a given row already exists. If it does, you would need to issue an UPDATE statement or an INSERT statement otherwise. Instead, you can write one statement with a matching condition that will do the INSERT or UPDATE automatically for you.
Imagine every night you get a file with updated data from all the countries in the world. Some countries may have reported new population numbers, and very occasionally, a new country is formed. Instead of running a bunch of UPDATE statements and rerunning the corresponding INSERT statement only when an UPDATE statement returns 0 rows updated, you can do both with one MERGE statement.
First, load all the data into an empty staging table (in this example, my_tab), and from there run the MERGE statement to merge the data into the target table (in this example, the countries table):
SQL> MERGE INTO countries c
2 USING my_tab m
3 ON (c.country_id=m.country_id)
4 WHEN NOT MATCHED THEN
5 INSERT VALUES (m.country_id, m.country_code, m.name, m.official_name, m.population, m.area_sq_km, m.latitude, m.longitude, m.timezone, m.region_id)
6 WHEN MATCHED THEN
7* UPDATE SET c.population=m.population;
196 rows merged.
The statement above merges data into the countries table based on matching country_id (primary key) values. If the countries table includes a row with the same country_id value as the my_tab table, then the statement just updates the population column (as seen within the WHEN MATCHED THEN UPDATE clause). If the MERGE statement doesn’t find a corresponding row with the same country_id values in the countries table, then it inserts the row with all the fields into the countries table.
The MERGE statement also provides some flexibility. Say that you just want to update the countries table but never insert into it. You can just omit the WHEN NOT MATCHED INSERT clause:
SQL> MERGE INTO countries c
2 USING my_tab m
3 ON (c.country_id=m.country_id)
4 WHEN MATCHED THEN
5* UPDATE SET c.population=m.population;
196 rows merged.
Conclusion
SQL is a powerful, widely adopted, declarative language for data processing and data manipulation. Understanding the core components of SQL and how it operates is the first step to unleashing its power on your data.
The data model used in this blog post can be found at: https://github.com/gvenzl/sample-data/tree/main/countries-cities-currencies
This blog post was originally published in two parts on The New Stack: How to Write SQL Queries and How to Use Data Manipulation Language (DML) in SQL
