Not too long ago, I responded to an email list regarding the storage of Oracle Database’s extended VARCHAR2 data types, which allow you to store up to 32 KB of data. Because the LOB layer is used to store the data, it is often misunderstood that extended VARCHAR2s are nothing but tiny CLOBs and fall under the same semantic rules as CLOBs, such as character set conversion when the database uses a variable-width character set. That is only natural, as such internal behavior like storage isn’t necessarily documented in the Oracle Database Documentation, and users can clearly see that LOB segments are created alongside the extended VARCHAR2 column. However, CLOBs have gotten somewhat of a bad reputation for their character set conversions over the years, and that was also quickly brought up as a downside for using the extended VARCHAR2s.
Table of Contents
- A common misconception
- What’s happening under the hood?
- Why do CLOBs use a 2-byte fixed-width character set anyway?
- Are CLOB characters always converted?
A common misconception
You need to be very confident that you need to do this – and you need to careful about character sets.
Critically – if you’re using a multibyte character set the extended datatypes will be stored in a fixed-width 2-byte character set. If most of your character data is actually using single byte “code points” then the data size will double because it’s now a clob. Here’s a little bit of a block dump to demonstrate.
I’ve got a table (v1 varchar2(30), c1 clob), and I’ve stored the value rpad(‘x’,30,’x’) in a row, my character set is AL32UtF8 (Note – I don’t have a database at hand with extended max_string_size, but using a declared CLOB for the demo is a valid mechanism).
tab 0, row 0, @0x1ab6
tl: 125 fb: –H-FL– lb: 0x1 cc: 2
col 0: [30]
78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78
78 78 78 78 78
col 1: [90]
00 70 00 01 02 0c 80 80 00 02 00 00 00 01 00 00 00 38 c0 c1 00 46 48 90 00
40 00 00 3c 01 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00
78 00 78 00 78 00 78 00 78 00 78 00 78 00 78The varchar2(30) column holds 30 bytes of data as ‘x’ is a single-byte code-point.
The clob column holds 90 bytes of data – ‘x’ becomes a two-byte code point accounting for 60 bytes, with a 30 byte LOB Locator overhead.
Note, also, that the LOB limit is 3.960 (approx) BYTES, so varchar2 of 1,981 (single byte) characters as a varchar2 will go out of line as a 3,962 byte LOB.
Indeed, it was misunderstood that an extended VARCHAR2 is the same as a CLOB but that is not the case. Instead, the same VARCHAR2 semantics are preserved, just like if it were a VARCHAR2 4k or VARCHAR2 1 byte and data will be stored in the database character set, regardless of the size of the string.
What’s happening under the hood?
To verify that the characters are not converted, the block dumping method can be used, as alluded to above. For that, I will create a new empty tablespace that will make that exercise a bit simpler, as we can’t dump the wrong blocks, and inside that tablespace, a new table TEST with a vc VARCHAR2(10) column, a ev VARCHAR2(32767) extended column, and a c CLOB column:
Setup
SQL> CREATE BIGFILE TABLESPACE test DATAFILE '/opt/oracle/oradata/ORCLCDB/ORCLPDB1/test.dbf' SIZE 10m;
Tablespace created.
SQL> CREATE TABLE test
(
vc VARCHAR2(10),
ev VARCHAR2(32767),
c CLOB
)
TABLESPACE test;
Table created.
Test data
Next, I’m loading 10 bytes of the letter x in all three of the columns. I’m using an elaborate WITH statement so that the x character input is only generated once, but also just for good measure, to showcase how you can use a WITH statement with an INSERT statement :). The same effect would have been accomplished by repeating RPAD('x',10'x') three times in a VALUES clause :
SQL> INSERT INTO test (vc, ev, c)
WITH source AS
(
SELECT RPAD('x',10,'x') AS input
)
SELECT input, input, input FROM source;
1 row created.
SQL> COMMIT;
Commit complete.
Block dump
Once the data is stored, the block(s) can be dumped. The ALTER SYSTEM DUMP DATAFILE n BLOCK m; syntax will dump a block into a trace file. For that, however, the data file number and the block number need to be known. The data file number is retrievable from v$datafile and the block number can be extracted from the rowid of the row in question:
SQL> -- The new tablespace uses data file name 'test.dbf'
SQL> SELECT file#, name FROM v$datafile;
FILE# NAME
---------- --------------------------------------------------
12 /opt/oracle/oradata/ORCLCDB/ORCLPDB1/system01.dbf
13 /opt/oracle/oradata/ORCLCDB/ORCLPDB1/sysaux01.dbf
14 /opt/oracle/oradata/ORCLCDB/ORCLPDB1/undotbs01.dbf
15 /opt/oracle/oradata/ORCLCDB/ORCLPDB1/users01.dbf
16 /opt/oracle/oradata/ORCLCDB/ORCLPDB1/test.dbf
SQL> -- There is only one row so we can just get the ROWID from that one row without a WHERE clause
SQL> SELECT dbms_rowid.rowid_block_number(rowid) FROM test;
DBMS_ROWID.ROWID_BLOCK_NUMBER(ROWID)
------------------------------------
783
SQL> ALTER SYSTEM DUMP DATAFILE 16 BLOCK 783;
System altered.
After the ALTER SYSTEM DUMP command, a new trace file has been written with the block content. Here is the entire block dump:
Data block dump file
Trace file /opt/oracle/diag/rdbms/orclcdb/ORCLCDB/trace/ORCLCDB_ora_1385813.trc
Oracle AI Database 26ai Enterprise Edition Release 23.26.0.0.0 - for Oracle Cloud and Engineered Systems
Version 23.26.0.0.0
Build label: RDBMS_23.26.0.0.0DBRU_LINUX.X64_250926.1
ORACLE_HOME: /opt/oracle/product/dbhome_23.26.0
System name: Linux
Node name: gvenzl-sql-analysis
Release: 5.15.0-313.189.5.1.el8uek.x86_64
Version: #2 SMP Fri Oct 10 11:37:53 PDT 2025
Machine: x86_64
VM name: KVM CPUID feature flags: 0x0100fafb
CLID: P
Instance name: ORCLCDB
Instance number: 1
Database name: ORCLCDB
Database unique name: ORCLCDB
Database id: 2977810247
Database role: PRIMARY
Redo thread mounted by this instance: 1
Oracle binary inode: 470306763
Oracle process number: 98
Unix process pid: 1385813
NID: 4026531836
created: 2025-12-17T14:26:24.-2036815636+00:00
image: oracle@gvenzl-sql-analysis (TNS V1-V3)
*** 2025-12-17T14:30:18.910648+00:00 (ORCLPDB1(3))
*** SESSION ID:(264.1161) 2025-12-17T14:30:18.910657+00:00
*** CLIENT ID:() 2025-12-17T14:30:18.910664+00:00
*** SERVICE NAME:(orclpdb1) 2025-12-17T14:30:18.910669+00:00
*** MODULE NAME:(sqlplus@gvenzl-sql-analysis (TNS V1-V3)) 2025-12-17T14:30:18.910675+00:00
*** ACTION NAME:() 2025-12-17T14:30:18.910681+00:00
*** CLIENT DRIVER:(SQL*PLUS) 2025-12-17T14:30:18.910686+00:00
*** CONTAINER ID:(3) 2025-12-17T14:30:18.910692+00:00
*** CLIENT IP:(N/A) 2025-12-17T14:30:18.910698+00:00
*** CONNECTION ID:(RiehGa1PJVTgY0kBAApzwA==) 2025-12-17T14:30:18.910704+00:00
Start dump data blocks tsn: 7 file#:16 minblk 783 maxblk 783
Block dump from cache:
Dump of buffer cache at level 3 for pdb=3 tsn=7 rdba=783
BH (0x467fa3270) file#: 16 rdba: 0x0000030f (1024/783) class: 1 ba: 0x4676b0000
set: 20 pool: 3 bsz: 8192 bsi: 0 sflg: 2 pwc: 0,0
dbwrid: 0 obj: 150645 objn: 150645 tsn: [3/7] afn: 16 hint: 0xf
hash: [0xdef01120,0xdef01120] lru: [0x49ffd8788,0x49bd7aba8]
ckptq: [NULL] fileq: [NULL]
objq: [0xf20d60e8,0xf20d60e8] objaq: [0xf20d60d8,0xf20d60d8] qhead: 0xf20d60c8
st: XCURRENT md: NULL fpin: 'ktspbwh2: ktspfmdb' fscn: 0x2a883cd fcur_vldr: 0x3 tch: 2
flags: block_written_once
LRBA: [0x0.0.0] LSCN: [0x0] HSCN: [0x2a883cd] HSUB: [1]
Printing buffer operation history (latest change first): (cnt 13)
01. sid:09 L192:kcbbic2:bic:FBD 02. sid:09 L191:kcbbic2:bic:FBW
03. sid:09 L602:bic1_int:bis:FWC 04. sid:09 L822:bic1_int:ent:rtn
05. sid:09 L832:oswmqbg1:clr:WRT 06. sid:09 L930:kubc:sw:mq
07. sid:09 L913:bxsv:sw:objq 08. sid:09 L608:bxsv:bis:FBW
09. sid:09 L607:bxsv:bis:FFW 10. sid:01 L464:chg1_mn:bic:FMS
11. sid:01 L778:chg1_mn:bis:FMS 12. sid:01 L552:chg_main:bic:CLN
13. sid:01 L353:gcur:set:MEXCL 14. sid:01 L464:chg1_mn:bic:FMS
buffer tsn: 7 rdba: 0x0000030f (1024/783)
scn: 0x2a883cf seq: 0x01 flg: 0x06 tail: 0x83cf0601
frmt: 0x02 chkval: 0x17c5 type: 0x06=trans data
Hex dump of block: st=0, typ_found=1
Dumping 'block' addr=0x4676b0000 size=8192 bytes
Dump of memory from 0x4676b0000 to 0x4676b2000
4676B0000 0000A206 0000030F 02A883CF 06010000 [................]
4676B0010 000017C5 00405F01 00024C75 02A883CD [....._@.uL......]
4676B0020 00008000 00320002 00000308 00000002 [......2.........]
4676B0030 00004254 00000273 0004116A 00002001 [TB..s...j.... ..]
4676B0040 02A883CF 00000000 00000000 00000000 [................]
4676B0050 00000000 00000000 00000000 00000000 [................]
4676B0060 00000000 00010100 0014FFFF 1F1A1F2E [................]
4676B0070 00001F1A 1F2E0001 01E901B0 02730238 [............8.s.]
4676B0080 02E602AC 0359031E 03CD0394 04430407 [......Y.......C.]
4676B0090 04BA047F 052E04F3 05B1056F 064005F8 [........o.....@.]
4676B00A0 06D00686 07520712 07DD0796 08670820 [......R..... .g.]
4676B00B0 08DB08A1 09520919 09CA098C 0A420A09 [......R.......B.]
4676B00C0 0AB90A7C 0B3B0AFF 0BB30B77 0C280BED [|.....;.w.....(.]
4676B00D0 0CA30C66 0D170CDD 0D980D53 0E2A0DE9 [f.......S.....*.]
4676B00E0 0E9F0E65 0F280EEA 0FAE0F64 102E0FE8 [e.....(.d.......]
4676B00F0 10A6106A 112110E7 119A115C 121411D8 [j.....!.\.......]
4676B0100 1288124E 130012C3 137A133C 13F613BB [N.......<.z.....]
4676B0110 146A1430 14E314A6 155D151F 15D51599 [0.j.......].....]
4676B0120 164B160F 16C31687 173E1700 17B8177C [..K.......>.|...]
4676B0130 182E17F2 18A21869 191618DC 19921956 [....i.......V...]
4676B0140 1A0619CC 1A8F1A4E 1B091AC9 1B801B44 [....N.......D...]
4676B0150 1BFC1BBC 1C7E1C3F 1CF71CB9 1D7D1D31 [....?.~.....1.}.]
4676B0160 1E081DC8 1E7B1E42 1EED1EB4 1F5F1F26 [....B.{.....&._.]
4676B0170 00000000 00000000 00000000 00000000 [................]
Repeat 5 times
4676B01D0 00000000 00000000 2C000000 C2031201 [...........,....]
4676B01E0 C5060F23 491C1027 02C10230 2827C506 [#...'..I0.....'(]
4676B01F0 01120659 01800180 01800180 01800180 [Y...............]
4676B0200 01800180 01800180 06800180 524E1EC5 [..............NR]
4676B0210 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B0220 C1023049 05C50602 60463F41 80018001 [I0......A?F`....]
4676B0230 80018001 80018001 80018001 80018001 [................]
4676B0240 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B0250 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B0260 124E1809 10C10214 1416C405 C3041F21 [..N.........!...]
4676B0270 03621F17 056002C2 303414C4 4BC30461 [..b...`...40a..K]
4676B0280 C3042420 01031E17 01800180 03800180 [ $..............]
4676B0290 06411BC2 524E1EC5 80013003 0312012C [..A...NR.0..,...]
4676B02A0 060F23C2 1C1027C5 C1023049 0FC50602 [.#...'..I0......]
4676B02B0 171E585D 0210C102 800102C1 80018001 []X..............]
4676B02C0 80018001 80018001 80018001 C5068001 [................]
4676B02D0 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B02E0 491C1027 02C10230 240FC506 01115D57 ['..I0......$W]..]
4676B02F0 01800180 01800180 01800180 01800180 [................]
4676B0300 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B0310 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B0320 03C50602 46442857 0109C102 01800180 [....W(DF........]
4676B0330 01800180 01800180 01800180 01800180 [................]
4676B0340 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B0350 27C5060F 30491C10 0502C102 351D3FC4 [...'..I0.....?.5]
4676B0360 01800129 01800180 01800180 01800180 [)...............]
4676B0370 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B0380 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B0390 0602C102 4C341DC5 80012D0A 1816C203 [......4L.-......]
4676B03A0 80018001 80018001 80018001 80018001 [................]
4676B03B0 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B03C0 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B03D0 3F0A6105 03800143 011816C2 01800180 [.a.?C...........]
4676B03E0 01800180 01800180 01800180 06800180 [................]
4676B03F0 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
4676B0400 1C1027C5 C1023049 02C50602 3B244C2A [.'..I0......*L$;]
4676B0410 80018001 80018001 80018001 80018001 [................]
4676B0420 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
4676B0430 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B0440 C50602C1 60290B09 09C10256 80018001 [......)`V.......]
4676B0450 80018001 80018001 80018001 80018001 [................]
4676B0460 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
4676B0470 C5060F23 491C1027 02C10230 3803C506 [#...'..I0......8]
4676B0480 022A211E C20305C1 80011816 80018001 [.!*.............]
4676B0490 80018001 80018001 80018001 C5068001 [................]
4676B04A0 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B04B0 491C1027 02C10230 5917C506 02403564 ['..I0......Yd5@.]
4676B04C0 C20305C1 80011816 80018001 80018001 [................]
4676B04D0 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B04E0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B04F0 02C10230 252BC506 01213209 16C20380 [0.....+%.2!.....]
4676B0500 01800118 01800180 01800180 01800180 [................]
4676B0510 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B0520 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B0530 1A2214C5 80013A10 80018001 80018001 [.."..:..........]
4676B0540 80018001 80018001 80018001 C5068001 [................]
4676B0550 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B0560 491C1027 02C10230 6226C506 01482D34 ['..I0.....&b4-H.]
4676B0570 16C20380 01800118 01800180 01800180 [................]
4676B0580 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B0590 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B05A0 0602C102 37011BC5 C1026257 21C30408 [.......7Wb.....!]
4676B05B0 C2033F35 80013F09 80018001 3F09C203 [5?...?.........?]
4676B05C0 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B05D0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B05E0 02C10230 151BC506 024B4721 C40508C1 [0.......!GK.....]
4676B05F0 3E543609 5B05C203 80018001 C2038001 [.6T>...[........]
4676B0600 80015B05 80018001 80018001 4E1EC506 [.[.............N]
4676B0610 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
4676B0620 0230491C C50602C1 4C021219 06C1021B [.I0........L....]
4676B0630 3B09C405 C3045640 020B2420 800111C1 [...;@V.. $......]
4676B0640 C3048001 015F2320 01800180 03800180 [.... #_.........]
4676B0650 063D02C2 524E1EC5 80013003 0312012C [..=...NR.0..,...]
4676B0660 060F23C2 1C1027C5 C1023049 0CC50602 [.#...'..I0......]
4676B0670 1941024A 0507C102 1B0902C4 13C30441 [J.A.........A...]
4676B0680 C1022D0F 02C10212 C3048001 011E0F13 [.-..............]
4676B0690 01800180 03800180 063C05C2 524E1EC5 [..........<...NR]
4676B06A0 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B06B0 C1023049 0CC50602 1E48015E 0510C102 [I0......^.H.....]
4676B06C0 0D5802C4 0DC3044F C1023E13 01800102 [..X.O....>......]
4676B06D0 0DC30480 80013D13 80018001 C1028001 [.....=..........]
4676B06E0 1EC5060E 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B06F0 27C5060F 30491C10 0602C102 1D6109C5 [...'..I0......a.]
4676B0700 C1021A4C 02C40506 04251D3D 2B3C07C3 [L.......=.%...<+]
4676B0710 0402C102 543548C3 0402C102 2A3C07C3 [.....H5T......<*]
4676B0720 80018001 80018001 0609C102 524E1EC5 [..............NR]
4676B0730 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B0740 C1023049 0FC50602 32523C5D C3048001 [I0......]<R2....]
4676B0750 03580B12 022215C2 800106C1 C2038001 [..X...".........]
4676B0760 80011D15 80018001 C1028001 1EC5064A [............J...]
4676B0770 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B0780 30491C10 0602C102 421C06C5 80014356 [..I0.......BVC..]
4676B0790 4516C304 14C2030C 01800114 03800180 [...E............]
4676B07A0 011414C2 01800180 01800180 1EC50680 [................]
4676B07B0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B07C0 30491C10 0602C102 1C3816C5 C1023315 [..I0......8..3..]
4676B07D0 05C40507 044B5C39 382B03C3 80018001 [....9\K...+8....]
4676B07E0 C3048001 01382B03 01800180 01800180 [.....+8.........]
4676B07F0 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B0800 27C5060F 30491C10 0602C102 5C4A08C5 [...'..I0......J\]
4676B0810 C1025651 12C50608 25380527 620CC304 [QV......'.8%...b]
4676B0820 03C1021B 80018001 620CC304 01800119 [...........b....]
4676B0830 01800180 22C10280 4E1EC506 01300352 [......."...NR.0.]
4676B0840 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B0850 C50602C1 472C3609 09C1022E 0909C304 [.....6,G........]
4676B0860 03C10213 C3048001 02605708 C10202C1 [.........W`.....]
4676B0870 01800103 01800180 06800180 524E1EC5 [..............NR]
4676B0880 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B0890 C1023049 2BC50602 0424555A 0409C102 [I0.....+ZU$.....]
4676B08A0 44451CC3 0231C102 C40530C1 2D072F02 [..ED..1..0.../.-]
4676B08B0 020BC102 800107C1 80018001 C2038001 [................]
4676B08C0 C5065C24 03524E1E 2C800130 C2031201 [$\...NR.0..,....]
4676B08D0 C5060F23 491C1027 02C10230 1D08C506 [#...'..I0.......]
4676B08E0 02505B2C 800109C1 80018001 80018001 [,[P.............]
4676B08F0 80018001 80018001 80018001 4E1EC506 [...............N]
4676B0900 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
4676B0910 0230491C C50602C1 12312C0C 09C10228 [.I0......,1.(...]
4676B0920 80018001 80018001 80018001 80018001 [................]
4676B0930 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
4676B0940 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
4676B0950 5916C506 025E3F2F C20303C1 C1021816 [...Y/?^.........]
4676B0960 01800105 02800180 800105C1 80018001 [................]
4676B0970 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B0980 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B0990 085F350C 01800129 01800180 01800180 [.5_.)...........]
4676B09A0 01800180 01800180 01800180 1EC50680 [................]
4676B09B0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B09C0 30491C10 0602C102 292F27C5 C1021A4A [..I0.....'/)J...]
4676B09D0 01800106 01800180 01800180 01800180 [................]
4676B09E0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B09F0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B0A00 04C50602 1E1C0119 0306C102 021816C2 [................]
4676B0A10 800104C1 80018001 0104C102 01800180 [................]
4676B0A20 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B0A30 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B0A40 5A4722C5 C1024850 13C30406 C1025209 [."GZPH.......R..]
4676B0A50 01800105 02800180 800105C1 80018001 [................]
4676B0A60 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B0A70 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B0A80 42261D2B 0180010F 01800180 01800180 [+.&B............]
4676B0A90 01800180 01800180 01800180 1EC50680 [................]
4676B0AA0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B0AB0 30491C10 0602C102 5E5B05C5 C1023E09 [..I0......[^.>..]
4676B0AC0 01800105 01800180 01800180 01800180 [................]
4676B0AD0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B0AE0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B0AF0 21C50602 24162842 0408C102 2D4314C3 [...!B(.$......C-]
4676B0B00 80018001 80018001 80018001 80018001 [................]
4676B0B10 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B0B20 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B0B30 1C17320E 0EC1022F 1C08C304 32C1020C [.2../..........2]
4676B0B40 0402C102 1D4908C3 6407C203 0131C102 [......I....d..1.]
4676B0B50 01800180 02800180 C50621C1 03524E1E [.........!...NR.]
4676B0B60 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B0B70 02C10230 2224C506 02070F4D C2030CC1 [0.....$"M.......]
4676B0B80 80011816 80018001 80018001 80018001 [................]
4676B0B90 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
4676B0BA0 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
4676B0BB0 240EC506 020D5440 C2030DC1 80011816 [...$@T..........]
4676B0BC0 80018001 80018001 80018001 80018001 [................]
4676B0BD0 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
4676B0BE0 C5060F23 491C1027 02C10230 2326C506 [#...'..I0.....&#]
4676B0BF0 023C5055 C2030BC1 80011816 80018001 [UP<.............]
4676B0C00 80018001 80018001 80018001 C5068001 [................]
4676B0C10 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B0C20 491C1027 02C10230 2119C506 02022103 ['..I0......!.!..]
4676B0C30 80010EC1 80018001 80018001 80018001 [................]
4676B0C40 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
4676B0C50 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B0C60 C50602C1 30493127 09C1022B 0103C102 [....'1I0+.......]
4676B0C70 01800180 01800180 01800180 01800180 [................]
4676B0C80 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B0C90 060F23C2 1C1027C5 C1023049 1CC50602 [.#...'..I0......]
4676B0CA0 1564581D 0307C102 022B3CC2 800102C1 [.Xd......<+.....]
4676B0CB0 80018001 0102C102 01800180 01800180 [................]
4676B0CC0 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B0CD0 27C5060F 30491C10 0602C102 1F2518C5 [...'..I0......%.]
4676B0CE0 C102070A 1AC20307 01800120 08C10280 [........ .......]
4676B0CF0 80018001 80018001 80018001 C5068001 [................]
4676B0D00 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B0D10 491C1027 02C10230 5F12C506 02023C49 ['..I0......_I<..]
4676B0D20 800106C1 80018001 80018001 80018001 [................]
4676B0D30 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
4676B0D40 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B0D50 C50602C1 3B153428 0AC10211 80018001 [....(4.;........]
4676B0D60 80018001 80018001 80018001 80018001 [................]
4676B0D70 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
4676B0D80 C5060F23 491C1027 02C10230 1213C506 [#...'..I0.......]
4676B0D90 02262714 C2030BC1 80011816 80018001 [.'&.............]
4676B0DA0 80018001 80018001 80018001 C5068001 [................]
4676B0DB0 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B0DC0 491C1027 02C10230 492AC506 025F5637 ['..I0.....*I7V_.]
4676B0DD0 C40507C1 463F440A 2B02C203 0104C102 [.....D?F...+....]
4676B0DE0 03800180 012802C2 01800180 03800180 [......(.........]
4676B0DF0 063A27C2 524E1EC5 80013003 0312012C [.':...NR.0..,...]
4676B0E00 060F23C2 1C1027C5 C1023049 28C50602 [.#...'..I0.....(]
4676B0E10 5C5A3D28 050EC102 142A11C4 02C40556 [(=Z\......*.V...]
4676B0E20 02244747 C40523C1 311F6410 4C04C405 [GG$..#...d.1...L]
4676B0E30 C405403C 03474702 80018001 80018001 [<@...GG.........]
4676B0E40 040CC203 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B0E50 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B0E60 49484A0D 09C1021B 4516C304 0FC2030C [.JHI.......E....]
4676B0E70 01800148 03800180 01480FC2 01800180 [H.........H.....]
4676B0E80 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B0E90 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B0EA0 081E23C5 C1023506 04C10206 80018001 [.#...5..........]
4676B0EB0 80018001 80018001 80018001 80018001 [................]
4676B0EC0 4E1EC506 01300352 12012C80 0F23C203 [...NR.0..,....#.]
4676B0ED0 1027C506 0230491C C50602C1 0A272916 [..'..I0......)'.]
4676B0EE0 0FC10208 80018001 80018001 80018001 [................]
4676B0EF0 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B0F00 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B0F10 02C10230 0617C506 020F4044 C50610C1 [0.......D@......]
4676B0F20 011B5B02 03C4054D 031B3104 011A02C2 [.[..M....1......]
4676B0F30 05800180 300403C4 01800102 01800180 [.......0........]
4676B0F40 1EC20380 1EC50634 3003524E 012C8001 [....4...NR.0..,.]
4676B0F50 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B0F60 64151FC5 C1023C5E 2BC20306 03C1024D [...d^<.....+M...]
4676B0F70 80018001 C1028001 01800103 01800180 [................]
4676B0F80 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B0F90 060F23C2 1C1027C5 C1023049 06C50602 [.#...'..I0......]
4676B0FA0 59580422 0305C102 011816C2 01800180 [".XY............]
4676B0FB0 01800180 01800180 01800180 06800180 [................]
4676B0FC0 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
4676B0FD0 1C1027C5 C1023049 0FC50602 41151539 [.'..I0......9..A]
4676B0FE0 0605C102 5B2D0DC5 C304572E 021D0705 [......-[.W......]
4676B0FF0 C20313C1 80014502 0705C304 0180010B [.....E..........]
4676B1000 01800180 03C20380 1EC50655 3003524E [........U...NR.0]
4676B1010 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B1020 0602C102 330108C5 80013D0D 0106C102 [.......3.=......]
4676B1030 01800180 01800180 01800180 01800180 [................]
4676B1040 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B1050 060F23C2 1C1027C5 C1023049 14C50602 [.#...'..I0......]
4676B1060 1907351F 0306C102 021916C2 800102C1 [.5..............]
4676B1070 0A0DC506 045B484B 181405C3 0102C102 [....KH[.........]
4676B1080 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B1090 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B10A0 0602C102 401407C5 C1020708 16C20307 [.......@........]
4676B10B0 01800118 01800180 01800180 01800180 [................]
4676B10C0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B10D0 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B10E0 292507C5 C1021C54 02C20305 01800120 [..%)T....... ...]
4676B10F0 01800180 01800180 01800180 01800180 [................]
4676B1100 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B1110 27C5060F 30491C10 0602C102 32331EC5 [...'..I0......32]
4676B1120 C102113B 36C30408 C2031913 80013832 [;......6....28..]
4676B1130 80018001 3832C203 80018001 80018001 [......28........]
4676B1140 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
4676B1150 C5060F23 491C1027 02C10230 084FC405 [#...'..I0.....O.]
4676B1160 C1024822 21C10203 80018001 80018001 ["H.....!........]
4676B1170 80018001 80018001 80018001 4E1EC506 [...............N]
4676B1180 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
4676B1190 0230491C C50602C1 2F430819 03800114 [.I0.......C/....]
4676B11A0 011816C2 01800180 01800180 01800180 [................]
4676B11B0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B11C0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B11D0 10C50602 630E160A 0303C102 021816C2 [.......c........]
4676B11E0 800102C1 80018001 0102C102 01800180 [................]
4676B11F0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B1200 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B1210 371105C5 C1021F02 16C20304 02C10218 [...7............]
4676B1220 80018001 C1028001 01800102 01800180 [................]
4676B1230 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B1240 060F23C2 1C1027C5 C1023049 26C50602 [.#...'..I0.....&]
4676B1250 34070D41 0302C102 011816C2 01800180 [A..4............]
4676B1260 01800180 01800180 01800180 06800180 [................]
4676B1270 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
4676B1280 1C1027C5 C1023049 0AC50602 2E640E39 [.'..I0......9.d.]
4676B1290 0102C102 01800180 01800180 01800180 [................]
4676B12A0 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B12B0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B12C0 0602C102 3D271BC5 C1026419 01800103 [......'=.d......]
4676B12D0 01800180 01800180 01800180 01800180 [................]
4676B12E0 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B12F0 060F23C2 1C1027C5 C1023049 14C50602 [.#...'..I0......]
4676B1300 4202581B 0203C102 800121C1 80018001 [.X.B.....!......]
4676B1310 80018001 80018001 80018001 C5068001 [................]
4676B1320 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B1330 491C1027 02C10230 5C05C506 025A0435 ['..I0......\5.Z.]
4676B1340 C20207C1 02C1021B 80018001 C1028001 [................]
4676B1350 01800102 01800180 06800180 524E1EC5 [..............NR]
4676B1360 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B1370 C1023049 1BC50602 34591702 0307C102 [I0........Y4....]
4676B1380 015305C2 01800180 01800180 01800180 [..S.............]
4676B1390 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B13A0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B13B0 1CC50602 4A3F4914 0307C102 011B0FC2 [.....I?J........]
4676B13C0 03800180 014513C2 01800180 01800180 [......E.........]
4676B13D0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B13E0 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B13F0 2B590BC5 C1020E15 16C30407 C2030C45 [..Y+........E...]
4676B1400 80011E18 80018001 1E18C203 80018001 [................]
4676B1410 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
4676B1420 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
4676B1430 2228C506 024F2A54 C10207C1 01800126 [..("T*O.....&...]
4676B1440 01800180 01800180 01800180 01800180 [................]
4676B1450 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B1460 27C5060F 30491C10 0602C102 1A060EC5 [...'..I0........]
4676B1470 C1020864 01800107 01800180 01800180 [d...............]
4676B1480 01800180 01800180 06800180 524E1EC5 [..............NR]
4676B1490 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B14A0 C1023049 28C50602 0C1C5B5B 0107C102 [I0.....([[......]
4676B14B0 01800180 01800180 01800180 01800180 [................]
4676B14C0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
4676B14D0 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
4676B14E0 3E2F04C5 C102521F 18C20307 0180011B [../>.R..........]
4676B14F0 01800180 01800180 01800180 01800180 [................]
4676B1500 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B1510 27C5060F 30491C10 0602C102 49220CC5 [...'..I0......"I]
4676B1520 C1020451 19C30408 80016432 80018001 [Q.......2d......]
4676B1530 80018001 80018001 80018001 C5068001 [................]
4676B1540 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B1550 491C1027 02C10230 0905C506 0239453B ['..I0.......;E9.]
4676B1560 C20302C1 80011E16 80018001 80018001 [................]
4676B1570 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B1580 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B1590 02C10230 3506C506 02335B62 C20303C1 [0......5b[3.....]
4676B15A0 C1021E16 01800102 02800180 800102C1 [................]
4676B15B0 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
4676B15C0 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B15D0 C50602C1 04554F2A 03C10207 1816C203 [....*OU.........]
4676B15E0 80018001 80018001 80018001 80018001 [................]
4676B15F0 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B1600 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B1610 0E193023 04C1025E 1816C203 80018001 [#0..^...........]
4676B1620 80018001 80018001 80018001 80018001 [................]
4676B1630 4E1EC506 01300352 12012C80 0F23C203 [...NR.0..,....#.]
4676B1640 1027C506 0230491C C50602C1 135C1E17 [..'..I0.......\.]
4676B1650 03C10239 80018001 80018001 80018001 [9...............]
4676B1660 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B1670 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B1680 02C10230 5F1CC506 02193F5C C20304C1 [0......_\?......]
4676B1690 80011816 80018001 80018001 80018001 [................]
4676B16A0 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
4676B16B0 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
4676B16C0 2303C506 020F5E4E C20305C1 80011816 [...#N^..........]
4676B16D0 80018001 80018001 80018001 80018001 [................]
4676B16E0 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
4676B16F0 C5060F23 491C1027 02C10230 600EC506 [#...'..I0......`]
4676B1700 022B6359 C20307C1 80011816 80018001 [Yc+.............]
4676B1710 80018001 80018001 80018001 C5068001 [................]
4676B1720 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
4676B1730 491C1027 02C10230 0E13C506 02443527 ['..I0.......'5D.]
4676B1740 C30406C1 01140807 01800180 01800180 [................]
4676B1750 01800180 01800180 06800180 524E1EC5 [..............NR]
4676B1760 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B1770 C1023049 27C50602 3D28540D 0303C102 [I0.....'.T(=....]
4676B1780 021816C2 800102C1 80018001 0102C102 [................]
4676B1790 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B17A0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B17B0 0602C102 18221BC5 C1023359 03C40505 [......".Y3......]
4676B17C0 012E4F37 01800180 01800180 01800180 [7O..............]
4676B17D0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B17E0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B17F0 20C50602 213F2401 0303C102 011816C2 [... .$?!........]
4676B1800 01800180 01800180 01800180 01800180 [................]
4676B1810 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B1820 060F23C2 1C1027C5 C1023049 20C50602 [.#...'..I0..... ]
4676B1830 3B0B4302 0107C102 01800180 01800180 [.C.;............]
4676B1840 01800180 01800180 01800180 1EC50680 [................]
4676B1850 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B1860 30491C10 0602C102 4A4D29C5 C1022964 [..I0.....)MJd)..]
4676B1870 16C20307 01800118 01800180 01800180 [................]
4676B1880 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B1890 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B18A0 0602C102 4D1D26C5 C1025F4B 07C10207 [.....&.MK_......]
4676B18B0 80018001 80018001 80018001 80018001 [................]
4676B18C0 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B18D0 0F23C203 1027C506 0230491C C40502C1 [..#...'..I0.....]
4676B18E0 5C034E2F 0106C102 01800180 01800180 [/N.\............]
4676B18F0 01800180 01800180 01800180 1EC50680 [................]
4676B1900 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B1910 30491C10 0602C102 54110EC5 C1020B29 [..I0.......T)...]
4676B1920 01800103 01800180 01800180 01800180 [................]
4676B1930 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B1940 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B1950 1AC50602 0E03324E 0103C102 01800180 [....N2..........]
4676B1960 01800180 01800180 01800180 01800180 [................]
4676B1970 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B1980 27C5060F 30491C10 0602C102 36610AC5 [...'..I0......a6]
4676B1990 C102223F 08C40505 02145A40 800102C1 [?"......@Z......]
4676B19A0 80018001 0102C102 01800180 01800180 [................]
4676B19B0 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B19C0 27C5060F 30491C10 0602C102 1F3028C5 [...'..I0.....(0.]
4676B19D0 C1024863 16C20303 01800118 01800180 [cH..............]
4676B19E0 01800180 01800180 01800180 1EC50680 [................]
4676B19F0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B1A00 30491C10 0602C102 154C1DC5 C102394C [..I0......L.L9..]
4676B1A10 01800107 01800180 01800180 01800180 [................]
4676B1A20 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B1A30 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B1A40 13C50602 1F561912 0107C102 01800180 [......V.........]
4676B1A50 01800180 01800180 01800180 01800180 [................]
4676B1A60 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B1A70 27C5060F 30491C10 0602C102 330E07C5 [...'..I0.......3]
4676B1A80 C102561E 02C40506 0409642C 344826C3 [.V......,d...&H4]
4676B1A90 4B02C203 80018001 4626C304 0180014E [...K......&FN...]
4676B1AA0 01800180 3CC20380 1EC50637 3003524E [.......<7...NR.0]
4676B1AB0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B1AC0 0602C102 290315C5 80013812 0C02C405 [.......).8......]
4676B1AD0 C203493F 80016404 80018001 6404C203 [?I...d.........d]
4676B1AE0 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B1AF0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B1B00 02C10230 0B12C506 02396104 800105C1 [0........a9.....]
4676B1B10 80018001 80018001 80018001 80018001 [................]
4676B1B20 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B1B30 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B1B40 1B545006 06C10254 0A06C405 C1020C1D [.PT.T...........]
4676B1B50 01800102 02800180 800102C1 80018001 [................]
4676B1B60 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B1B70 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B1B80 5410260D 0380014A 011A16C2 01800180 [.&.TJ...........]
4676B1B90 01800180 01800180 01800180 06800180 [................]
4676B1BA0 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
4676B1BB0 1C1027C5 C1023049 02C50602 50423830 [.'..I0......08BP]
4676B1BC0 0309C102 01280DC2 01800180 01800180 [......(.........]
4676B1BD0 01800180 01800180 06800180 524E1EC5 [..............NR]
4676B1BE0 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
4676B1BF0 C1023049 19C50602 0D1E4239 0309C102 [I0......9B......]
4676B1C00 010603C2 01800180 01800180 01800180 [................]
4676B1C10 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B1C20 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B1C30 18C50502 02644A1A C30406C1 03065F2C [.....Jd.....,_..]
4676B1C40 015906C2 01800180 06C20380 01800159 [..Y.........Y...]
4676B1C50 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
4676B1C60 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
4676B1C70 26C50602 0B20255F 0506C102 070902C4 [...&_% .........]
4676B1C80 12C20340 02800125 800106C1 2512C203 [@...%..........%]
4676B1C90 80018001 80018001 C5068001 03524E1E [.............NR.]
4676B1CA0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
4676B1CB0 02C10230 3C19C506 02115101 C30407C1 [0......<.Q......]
4676B1CC0 02472B16 800105C1 80018001 0105C102 [.+G.............]
4676B1CD0 01800180 01800180 1EC50680 3003524E [............NR.0]
4676B1CE0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
4676B1CF0 0602C102 285320C5 C1025C3D 2BC10206 [..... S(=\.....+]
4676B1D00 80018001 80018001 80018001 80018001 [................]
4676B1D10 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
4676B1D20 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
4676B1D30 1121281E 05C1025A 1716C203 0102C102 [.(!.Z...........]
4676B1D40 01800180 02C10280 80018001 80018001 [................]
4676B1D50 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
4676B1D60 C5060F23 491C1027 02C10230 1207C506 [#...'..I0.......]
4676B1D70 012E6364 15C10280 80018001 80018001 [dc..............]
4676B1D80 80018001 80018001 80018001 4E1EC506 [...............N]
4676B1D90 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
4676B1DA0 0230491C C50602C1 381B010B 03C1021D [.I0........8....]
4676B1DB0 5223C405 C3044846 0317440E 03593EC2 [..#RFH...D...>Y.]
4676B1DC0 021903C2 C3044BC1 0139060E 01800180 [.....K....9.....]
4676B1DD0 04800180 602B0BC3 4E1EC506 01300352 [......+`...NR.0.]
4676B1DE0 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B1DF0 C50602C1 47623E1C 02C10230 1206C405 [.....>bG0.......]
4676B1E00 C2030820 C1024617 06C40516 03255F11 [ ....F......._%.]
4676B1E10 03180FC2 013117C2 01800180 03800180 [......1.........]
4676B1E20 062804C2 524E1EC5 80013003 0312012C [..(...NR.0..,...]
4676B1E30 060F23C2 1C1027C5 C1023049 0DC50602 [.#...'..I0......]
4676B1E40 051F235E 0406C102 195B27C3 0103C102 [^#.......'[.....]
4676B1E50 02C10280 C1028001 01800103 01800180 [................]
4676B1E60 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
4676B1E70 060F23C2 1C1027C5 C1023049 24C50602 [.#...'..I0.....$]
4676B1E80 55210917 0107C102 01800180 01800180 [..!U............]
4676B1E90 01800180 01800180 01800180 1EC50680 [................]
4676B1EA0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
4676B1EB0 30491C10 0602C102 133004C5 80014156 [..I0......0.VA..]
4676B1EC0 80018001 80018001 80018001 80018001 [................]
4676B1ED0 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
4676B1EE0 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
4676B1EF0 2722C506 0131431E 01800180 01800180 [.."'.C1.........]
4676B1F00 01800180 01800180 01800180 06800180 [................]
4676B1F10 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
4676B1F20 1C1027C5 C1023049 03C50602 24473E34 [.'..I0......4>G$]
4676B1F30 80018001 80018001 80018001 80018001 [................]
4676B1F40 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
4676B1F50 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
4676B1F60 C50602C1 5256541F 0180011A 01800180 [.....TVR........]
4676B1F70 01800180 01800180 01800180 01800180 [................]
4676B1F80 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
4676B1F90 012C060F 78780A03 78787878 78787878 [..,...xxxxxxxxxx]
4676B1FA0 00700028 000C0101 00010080 00010000 [(.p.............]
4676B1FB0 DE240000 48140017 000E0090 78010A00 [..$....H.......x]
4676B1FC0 78787878 78787878 70003278 0C020100 [xxxxxxxxx2.p....]
4676B1FD0 02008080 01000000 24000000 1E0018DE [...........$....]
4676B1FE0 18009048 01140000 78007800 78007800 [H........x.x.x.x]
4676B1FF0 78007800 78007800 78007800 83CF0601 [.x.x.x.x.x.x....]
Block scn: 0x2a883cf
Block header dump: 0x0000030f
Object id on Block? Y
seg/obj: 0x24c75 csc: 0x0000000002a883cd itc: 2 flg: E- typ: 1 - DATA
brn: 0 bdba: 0x308 ver: 0x01 opc: 0
inc: 0 exflg: 0
Itl Xid Uba Flag Lck Scn/Fsc
0x01 0x0002.000.00004254 0x00000273.116a.04 --U- 1 fsc 0x0000.02a883cf
0x02 0x0000.000.00000000 0x00000000.0000.00 ---- 0 fsc 0x0000.00000000
bdba: 0x0000030f type: 0x06 SAGE: 0
data_block_dump,data header at 0x4676b0064
===============
tsiz: 0x1f98
hsiz: 0x14
pbl: 0x4676b0064
76543210
flag=--------
ntab=1
nrow=1
frre=-1
fsbo=0x14
fseo=0x1f2e
avsp=0x1f1a
tosp=0x1f1a
0xe:pti[0] nrow=1 offs=0
0x12:pri[0] offs=0x1f2e
block_row_dump:
tab 0, row 0, @0x1f2e
tl: 106 fb: --H-FL-- lb: 0x1 cc: 3
col 0: [10] 78 78 78 78 78 78 78 78 78 78
col 1: [40]
00 70 00 01 01 0c 00 80 00 01 00 00 00 01 00 00 00 24 de 17 00 14 48 90 00
0e 00 00 0a 01 78 78 78 78 78 78 78 78 78 78
LOB
Locator:
Length: 112(40)
Version: 1
Byte Length: 1
LobID: 00.00.00.01.00.00.00.24.de.17
Flags[ 0x01 0x0c 0x00 0x80 ]:
Type: BLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: ReadWrite
SecureFile Header:
Length: 20
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:14
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 10
VER: 1
INLINE DATA (10):
78 78 78 78 78 78 78 78 78 78
col 2: [50]
00 70 00 01 02 0c 80 80 00 02 00 00 00 01 00 00 00 24 de 18 00 1e 48 90 00
18 00 00 14 01 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
LOB
Locator:
Length: 112(50)
Version: 1
Byte Length: 2
LobID: 00.00.00.01.00.00.00.24.de.18
Flags[ 0x02 0x0c 0x80 0x80 ]:
Type: CLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: VaringWidthReadWrite
SecureFile Header:
Length: 30
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:24
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 20
VER: 1
INLINE DATA (20):
00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
00 78 00 78
end_of_block_dump
Dump of buffer cache for pdb 3 tsn 7 rdba 0x30f at level 2 done.
Block dump from disk:
buffer tsn: 7 rdba: 0x0000030f (1024/783)
scn: 0x2a883cf seq: 0x01 flg: 0x06 tail: 0x83cf0601
frmt: 0x02 chkval: 0x17c5 type: 0x06=trans data
Hex dump of block: st=0, typ_found=1
Dumping 'block' addr=0x7f3c4f049000 size=8192 bytes
Dump of memory from 0x7f3c4f049000 to 0x7f3c4f04b000
7F3C4F049000 0000A206 0000030F 02A883CF 06010000 [................]
7F3C4F049010 000017C5 00405F01 00024C75 02A883CD [....._@.uL......]
7F3C4F049020 00008000 00320002 00000308 00000002 [......2.........]
7F3C4F049030 00004254 00000273 0004116A 00002001 [TB..s...j.... ..]
7F3C4F049040 02A883CF 00000000 00000000 00000000 [................]
7F3C4F049050 00000000 00000000 00000000 00000000 [................]
7F3C4F049060 00000000 00010100 0014FFFF 1F1A1F2E [................]
7F3C4F049070 00001F1A 1F2E0001 01E901B0 02730238 [............8.s.]
7F3C4F049080 02E602AC 0359031E 03CD0394 04430407 [......Y.......C.]
7F3C4F049090 04BA047F 052E04F3 05B1056F 064005F8 [........o.....@.]
7F3C4F0490A0 06D00686 07520712 07DD0796 08670820 [......R..... .g.]
7F3C4F0490B0 08DB08A1 09520919 09CA098C 0A420A09 [......R.......B.]
7F3C4F0490C0 0AB90A7C 0B3B0AFF 0BB30B77 0C280BED [|.....;.w.....(.]
7F3C4F0490D0 0CA30C66 0D170CDD 0D980D53 0E2A0DE9 [f.......S.....*.]
7F3C4F0490E0 0E9F0E65 0F280EEA 0FAE0F64 102E0FE8 [e.....(.d.......]
7F3C4F0490F0 10A6106A 112110E7 119A115C 121411D8 [j.....!.\.......]
7F3C4F049100 1288124E 130012C3 137A133C 13F613BB [N.......<.z.....]
7F3C4F049110 146A1430 14E314A6 155D151F 15D51599 [0.j.......].....]
7F3C4F049120 164B160F 16C31687 173E1700 17B8177C [..K.......>.|...]
7F3C4F049130 182E17F2 18A21869 191618DC 19921956 [....i.......V...]
7F3C4F049140 1A0619CC 1A8F1A4E 1B091AC9 1B801B44 [....N.......D...]
7F3C4F049150 1BFC1BBC 1C7E1C3F 1CF71CB9 1D7D1D31 [....?.~.....1.}.]
7F3C4F049160 1E081DC8 1E7B1E42 1EED1EB4 1F5F1F26 [....B.{.....&._.]
7F3C4F049170 00000000 00000000 00000000 00000000 [................]
Repeat 5 times
7F3C4F0491D0 00000000 00000000 2C000000 C2031201 [...........,....]
7F3C4F0491E0 C5060F23 491C1027 02C10230 2827C506 [#...'..I0.....'(]
7F3C4F0491F0 01120659 01800180 01800180 01800180 [Y...............]
7F3C4F049200 01800180 01800180 06800180 524E1EC5 [..............NR]
7F3C4F049210 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F049220 C1023049 05C50602 60463F41 80018001 [I0......A?F`....]
7F3C4F049230 80018001 80018001 80018001 80018001 [................]
7F3C4F049240 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F049250 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F049260 124E1809 10C10214 1416C405 C3041F21 [..N.........!...]
7F3C4F049270 03621F17 056002C2 303414C4 4BC30461 [..b...`...40a..K]
7F3C4F049280 C3042420 01031E17 01800180 03800180 [ $..............]
7F3C4F049290 06411BC2 524E1EC5 80013003 0312012C [..A...NR.0..,...]
7F3C4F0492A0 060F23C2 1C1027C5 C1023049 0FC50602 [.#...'..I0......]
7F3C4F0492B0 171E585D 0210C102 800102C1 80018001 []X..............]
7F3C4F0492C0 80018001 80018001 80018001 C5068001 [................]
7F3C4F0492D0 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F0492E0 491C1027 02C10230 240FC506 01115D57 ['..I0......$W]..]
7F3C4F0492F0 01800180 01800180 01800180 01800180 [................]
7F3C4F049300 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F049310 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F049320 03C50602 46442857 0109C102 01800180 [....W(DF........]
7F3C4F049330 01800180 01800180 01800180 01800180 [................]
7F3C4F049340 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F049350 27C5060F 30491C10 0502C102 351D3FC4 [...'..I0.....?.5]
7F3C4F049360 01800129 01800180 01800180 01800180 [)...............]
7F3C4F049370 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F049380 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F049390 0602C102 4C341DC5 80012D0A 1816C203 [......4L.-......]
7F3C4F0493A0 80018001 80018001 80018001 80018001 [................]
7F3C4F0493B0 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F0493C0 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F0493D0 3F0A6105 03800143 011816C2 01800180 [.a.?C...........]
7F3C4F0493E0 01800180 01800180 01800180 06800180 [................]
7F3C4F0493F0 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
7F3C4F049400 1C1027C5 C1023049 02C50602 3B244C2A [.'..I0......*L$;]
7F3C4F049410 80018001 80018001 80018001 80018001 [................]
7F3C4F049420 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
7F3C4F049430 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F049440 C50602C1 60290B09 09C10256 80018001 [......)`V.......]
7F3C4F049450 80018001 80018001 80018001 80018001 [................]
7F3C4F049460 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
7F3C4F049470 C5060F23 491C1027 02C10230 3803C506 [#...'..I0......8]
7F3C4F049480 022A211E C20305C1 80011816 80018001 [.!*.............]
7F3C4F049490 80018001 80018001 80018001 C5068001 [................]
7F3C4F0494A0 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F0494B0 491C1027 02C10230 5917C506 02403564 ['..I0......Yd5@.]
7F3C4F0494C0 C20305C1 80011816 80018001 80018001 [................]
7F3C4F0494D0 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F0494E0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F0494F0 02C10230 252BC506 01213209 16C20380 [0.....+%.2!.....]
7F3C4F049500 01800118 01800180 01800180 01800180 [................]
7F3C4F049510 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F049520 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F049530 1A2214C5 80013A10 80018001 80018001 [.."..:..........]
7F3C4F049540 80018001 80018001 80018001 C5068001 [................]
7F3C4F049550 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F049560 491C1027 02C10230 6226C506 01482D34 ['..I0.....&b4-H.]
7F3C4F049570 16C20380 01800118 01800180 01800180 [................]
7F3C4F049580 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F049590 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F0495A0 0602C102 37011BC5 C1026257 21C30408 [.......7Wb.....!]
7F3C4F0495B0 C2033F35 80013F09 80018001 3F09C203 [5?...?.........?]
7F3C4F0495C0 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F0495D0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F0495E0 02C10230 151BC506 024B4721 C40508C1 [0.......!GK.....]
7F3C4F0495F0 3E543609 5B05C203 80018001 C2038001 [.6T>...[........]
7F3C4F049600 80015B05 80018001 80018001 4E1EC506 [.[.............N]
7F3C4F049610 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
7F3C4F049620 0230491C C50602C1 4C021219 06C1021B [.I0........L....]
7F3C4F049630 3B09C405 C3045640 020B2420 800111C1 [...;@V.. $......]
7F3C4F049640 C3048001 015F2320 01800180 03800180 [.... #_.........]
7F3C4F049650 063D02C2 524E1EC5 80013003 0312012C [..=...NR.0..,...]
7F3C4F049660 060F23C2 1C1027C5 C1023049 0CC50602 [.#...'..I0......]
7F3C4F049670 1941024A 0507C102 1B0902C4 13C30441 [J.A.........A...]
7F3C4F049680 C1022D0F 02C10212 C3048001 011E0F13 [.-..............]
7F3C4F049690 01800180 03800180 063C05C2 524E1EC5 [..........<...NR]
7F3C4F0496A0 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F0496B0 C1023049 0CC50602 1E48015E 0510C102 [I0......^.H.....]
7F3C4F0496C0 0D5802C4 0DC3044F C1023E13 01800102 [..X.O....>......]
7F3C4F0496D0 0DC30480 80013D13 80018001 C1028001 [.....=..........]
7F3C4F0496E0 1EC5060E 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F0496F0 27C5060F 30491C10 0602C102 1D6109C5 [...'..I0......a.]
7F3C4F049700 C1021A4C 02C40506 04251D3D 2B3C07C3 [L.......=.%...<+]
7F3C4F049710 0402C102 543548C3 0402C102 2A3C07C3 [.....H5T......<*]
7F3C4F049720 80018001 80018001 0609C102 524E1EC5 [..............NR]
7F3C4F049730 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F049740 C1023049 0FC50602 32523C5D C3048001 [I0......]<R2....]
7F3C4F049750 03580B12 022215C2 800106C1 C2038001 [..X...".........]
7F3C4F049760 80011D15 80018001 C1028001 1EC5064A [............J...]
7F3C4F049770 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F049780 30491C10 0602C102 421C06C5 80014356 [..I0.......BVC..]
7F3C4F049790 4516C304 14C2030C 01800114 03800180 [...E............]
7F3C4F0497A0 011414C2 01800180 01800180 1EC50680 [................]
7F3C4F0497B0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F0497C0 30491C10 0602C102 1C3816C5 C1023315 [..I0......8..3..]
7F3C4F0497D0 05C40507 044B5C39 382B03C3 80018001 [....9\K...+8....]
7F3C4F0497E0 C3048001 01382B03 01800180 01800180 [.....+8.........]
7F3C4F0497F0 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F049800 27C5060F 30491C10 0602C102 5C4A08C5 [...'..I0......J\]
7F3C4F049810 C1025651 12C50608 25380527 620CC304 [QV......'.8%...b]
7F3C4F049820 03C1021B 80018001 620CC304 01800119 [...........b....]
7F3C4F049830 01800180 22C10280 4E1EC506 01300352 [......."...NR.0.]
7F3C4F049840 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F049850 C50602C1 472C3609 09C1022E 0909C304 [.....6,G........]
7F3C4F049860 03C10213 C3048001 02605708 C10202C1 [.........W`.....]
7F3C4F049870 01800103 01800180 06800180 524E1EC5 [..............NR]
7F3C4F049880 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F049890 C1023049 2BC50602 0424555A 0409C102 [I0.....+ZU$.....]
7F3C4F0498A0 44451CC3 0231C102 C40530C1 2D072F02 [..ED..1..0.../.-]
7F3C4F0498B0 020BC102 800107C1 80018001 C2038001 [................]
7F3C4F0498C0 C5065C24 03524E1E 2C800130 C2031201 [$\...NR.0..,....]
7F3C4F0498D0 C5060F23 491C1027 02C10230 1D08C506 [#...'..I0.......]
7F3C4F0498E0 02505B2C 800109C1 80018001 80018001 [,[P.............]
7F3C4F0498F0 80018001 80018001 80018001 4E1EC506 [...............N]
7F3C4F049900 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
7F3C4F049910 0230491C C50602C1 12312C0C 09C10228 [.I0......,1.(...]
7F3C4F049920 80018001 80018001 80018001 80018001 [................]
7F3C4F049930 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
7F3C4F049940 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
7F3C4F049950 5916C506 025E3F2F C20303C1 C1021816 [...Y/?^.........]
7F3C4F049960 01800105 02800180 800105C1 80018001 [................]
7F3C4F049970 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F049980 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F049990 085F350C 01800129 01800180 01800180 [.5_.)...........]
7F3C4F0499A0 01800180 01800180 01800180 1EC50680 [................]
7F3C4F0499B0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F0499C0 30491C10 0602C102 292F27C5 C1021A4A [..I0.....'/)J...]
7F3C4F0499D0 01800106 01800180 01800180 01800180 [................]
7F3C4F0499E0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F0499F0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F049A00 04C50602 1E1C0119 0306C102 021816C2 [................]
7F3C4F049A10 800104C1 80018001 0104C102 01800180 [................]
7F3C4F049A20 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F049A30 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F049A40 5A4722C5 C1024850 13C30406 C1025209 [."GZPH.......R..]
7F3C4F049A50 01800105 02800180 800105C1 80018001 [................]
7F3C4F049A60 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F049A70 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F049A80 42261D2B 0180010F 01800180 01800180 [+.&B............]
7F3C4F049A90 01800180 01800180 01800180 1EC50680 [................]
7F3C4F049AA0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F049AB0 30491C10 0602C102 5E5B05C5 C1023E09 [..I0......[^.>..]
7F3C4F049AC0 01800105 01800180 01800180 01800180 [................]
7F3C4F049AD0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F049AE0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F049AF0 21C50602 24162842 0408C102 2D4314C3 [...!B(.$......C-]
7F3C4F049B00 80018001 80018001 80018001 80018001 [................]
7F3C4F049B10 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F049B20 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F049B30 1C17320E 0EC1022F 1C08C304 32C1020C [.2../..........2]
7F3C4F049B40 0402C102 1D4908C3 6407C203 0131C102 [......I....d..1.]
7F3C4F049B50 01800180 02800180 C50621C1 03524E1E [.........!...NR.]
7F3C4F049B60 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F049B70 02C10230 2224C506 02070F4D C2030CC1 [0.....$"M.......]
7F3C4F049B80 80011816 80018001 80018001 80018001 [................]
7F3C4F049B90 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
7F3C4F049BA0 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
7F3C4F049BB0 240EC506 020D5440 C2030DC1 80011816 [...$@T..........]
7F3C4F049BC0 80018001 80018001 80018001 80018001 [................]
7F3C4F049BD0 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
7F3C4F049BE0 C5060F23 491C1027 02C10230 2326C506 [#...'..I0.....&#]
7F3C4F049BF0 023C5055 C2030BC1 80011816 80018001 [UP<.............]
7F3C4F049C00 80018001 80018001 80018001 C5068001 [................]
7F3C4F049C10 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F049C20 491C1027 02C10230 2119C506 02022103 ['..I0......!.!..]
7F3C4F049C30 80010EC1 80018001 80018001 80018001 [................]
7F3C4F049C40 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
7F3C4F049C50 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F049C60 C50602C1 30493127 09C1022B 0103C102 [....'1I0+.......]
7F3C4F049C70 01800180 01800180 01800180 01800180 [................]
7F3C4F049C80 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F049C90 060F23C2 1C1027C5 C1023049 1CC50602 [.#...'..I0......]
7F3C4F049CA0 1564581D 0307C102 022B3CC2 800102C1 [.Xd......<+.....]
7F3C4F049CB0 80018001 0102C102 01800180 01800180 [................]
7F3C4F049CC0 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F049CD0 27C5060F 30491C10 0602C102 1F2518C5 [...'..I0......%.]
7F3C4F049CE0 C102070A 1AC20307 01800120 08C10280 [........ .......]
7F3C4F049CF0 80018001 80018001 80018001 C5068001 [................]
7F3C4F049D00 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F049D10 491C1027 02C10230 5F12C506 02023C49 ['..I0......_I<..]
7F3C4F049D20 800106C1 80018001 80018001 80018001 [................]
7F3C4F049D30 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
7F3C4F049D40 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F049D50 C50602C1 3B153428 0AC10211 80018001 [....(4.;........]
7F3C4F049D60 80018001 80018001 80018001 80018001 [................]
7F3C4F049D70 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
7F3C4F049D80 C5060F23 491C1027 02C10230 1213C506 [#...'..I0.......]
7F3C4F049D90 02262714 C2030BC1 80011816 80018001 [.'&.............]
7F3C4F049DA0 80018001 80018001 80018001 C5068001 [................]
7F3C4F049DB0 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F049DC0 491C1027 02C10230 492AC506 025F5637 ['..I0.....*I7V_.]
7F3C4F049DD0 C40507C1 463F440A 2B02C203 0104C102 [.....D?F...+....]
7F3C4F049DE0 03800180 012802C2 01800180 03800180 [......(.........]
7F3C4F049DF0 063A27C2 524E1EC5 80013003 0312012C [.':...NR.0..,...]
7F3C4F049E00 060F23C2 1C1027C5 C1023049 28C50602 [.#...'..I0.....(]
7F3C4F049E10 5C5A3D28 050EC102 142A11C4 02C40556 [(=Z\......*.V...]
7F3C4F049E20 02244747 C40523C1 311F6410 4C04C405 [GG$..#...d.1...L]
7F3C4F049E30 C405403C 03474702 80018001 80018001 [<@...GG.........]
7F3C4F049E40 040CC203 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F049E50 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F049E60 49484A0D 09C1021B 4516C304 0FC2030C [.JHI.......E....]
7F3C4F049E70 01800148 03800180 01480FC2 01800180 [H.........H.....]
7F3C4F049E80 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F049E90 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F049EA0 081E23C5 C1023506 04C10206 80018001 [.#...5..........]
7F3C4F049EB0 80018001 80018001 80018001 80018001 [................]
7F3C4F049EC0 4E1EC506 01300352 12012C80 0F23C203 [...NR.0..,....#.]
7F3C4F049ED0 1027C506 0230491C C50602C1 0A272916 [..'..I0......)'.]
7F3C4F049EE0 0FC10208 80018001 80018001 80018001 [................]
7F3C4F049EF0 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F049F00 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F049F10 02C10230 0617C506 020F4044 C50610C1 [0.......D@......]
7F3C4F049F20 011B5B02 03C4054D 031B3104 011A02C2 [.[..M....1......]
7F3C4F049F30 05800180 300403C4 01800102 01800180 [.......0........]
7F3C4F049F40 1EC20380 1EC50634 3003524E 012C8001 [....4...NR.0..,.]
7F3C4F049F50 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F049F60 64151FC5 C1023C5E 2BC20306 03C1024D [...d^<.....+M...]
7F3C4F049F70 80018001 C1028001 01800103 01800180 [................]
7F3C4F049F80 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F049F90 060F23C2 1C1027C5 C1023049 06C50602 [.#...'..I0......]
7F3C4F049FA0 59580422 0305C102 011816C2 01800180 [".XY............]
7F3C4F049FB0 01800180 01800180 01800180 06800180 [................]
7F3C4F049FC0 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
7F3C4F049FD0 1C1027C5 C1023049 0FC50602 41151539 [.'..I0......9..A]
7F3C4F049FE0 0605C102 5B2D0DC5 C304572E 021D0705 [......-[.W......]
7F3C4F049FF0 C20313C1 80014502 0705C304 0180010B [.....E..........]
7F3C4F04A000 01800180 03C20380 1EC50655 3003524E [........U...NR.0]
7F3C4F04A010 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04A020 0602C102 330108C5 80013D0D 0106C102 [.......3.=......]
7F3C4F04A030 01800180 01800180 01800180 01800180 [................]
7F3C4F04A040 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F04A050 060F23C2 1C1027C5 C1023049 14C50602 [.#...'..I0......]
7F3C4F04A060 1907351F 0306C102 021916C2 800102C1 [.5..............]
7F3C4F04A070 0A0DC506 045B484B 181405C3 0102C102 [....KH[.........]
7F3C4F04A080 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F04A090 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04A0A0 0602C102 401407C5 C1020708 16C20307 [.......@........]
7F3C4F04A0B0 01800118 01800180 01800180 01800180 [................]
7F3C4F04A0C0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F04A0D0 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F04A0E0 292507C5 C1021C54 02C20305 01800120 [..%)T....... ...]
7F3C4F04A0F0 01800180 01800180 01800180 01800180 [................]
7F3C4F04A100 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04A110 27C5060F 30491C10 0602C102 32331EC5 [...'..I0......32]
7F3C4F04A120 C102113B 36C30408 C2031913 80013832 [;......6....28..]
7F3C4F04A130 80018001 3832C203 80018001 80018001 [......28........]
7F3C4F04A140 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
7F3C4F04A150 C5060F23 491C1027 02C10230 084FC405 [#...'..I0.....O.]
7F3C4F04A160 C1024822 21C10203 80018001 80018001 ["H.....!........]
7F3C4F04A170 80018001 80018001 80018001 4E1EC506 [...............N]
7F3C4F04A180 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
7F3C4F04A190 0230491C C50602C1 2F430819 03800114 [.I0.......C/....]
7F3C4F04A1A0 011816C2 01800180 01800180 01800180 [................]
7F3C4F04A1B0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04A1C0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04A1D0 10C50602 630E160A 0303C102 021816C2 [.......c........]
7F3C4F04A1E0 800102C1 80018001 0102C102 01800180 [................]
7F3C4F04A1F0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F04A200 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F04A210 371105C5 C1021F02 16C20304 02C10218 [...7............]
7F3C4F04A220 80018001 C1028001 01800102 01800180 [................]
7F3C4F04A230 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F04A240 060F23C2 1C1027C5 C1023049 26C50602 [.#...'..I0.....&]
7F3C4F04A250 34070D41 0302C102 011816C2 01800180 [A..4............]
7F3C4F04A260 01800180 01800180 01800180 06800180 [................]
7F3C4F04A270 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
7F3C4F04A280 1C1027C5 C1023049 0AC50602 2E640E39 [.'..I0......9.d.]
7F3C4F04A290 0102C102 01800180 01800180 01800180 [................]
7F3C4F04A2A0 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F04A2B0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04A2C0 0602C102 3D271BC5 C1026419 01800103 [......'=.d......]
7F3C4F04A2D0 01800180 01800180 01800180 01800180 [................]
7F3C4F04A2E0 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F04A2F0 060F23C2 1C1027C5 C1023049 14C50602 [.#...'..I0......]
7F3C4F04A300 4202581B 0203C102 800121C1 80018001 [.X.B.....!......]
7F3C4F04A310 80018001 80018001 80018001 C5068001 [................]
7F3C4F04A320 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F04A330 491C1027 02C10230 5C05C506 025A0435 ['..I0......\5.Z.]
7F3C4F04A340 C20207C1 02C1021B 80018001 C1028001 [................]
7F3C4F04A350 01800102 01800180 06800180 524E1EC5 [..............NR]
7F3C4F04A360 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F04A370 C1023049 1BC50602 34591702 0307C102 [I0........Y4....]
7F3C4F04A380 015305C2 01800180 01800180 01800180 [..S.............]
7F3C4F04A390 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04A3A0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04A3B0 1CC50602 4A3F4914 0307C102 011B0FC2 [.....I?J........]
7F3C4F04A3C0 03800180 014513C2 01800180 01800180 [......E.........]
7F3C4F04A3D0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F04A3E0 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F04A3F0 2B590BC5 C1020E15 16C30407 C2030C45 [..Y+........E...]
7F3C4F04A400 80011E18 80018001 1E18C203 80018001 [................]
7F3C4F04A410 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
7F3C4F04A420 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
7F3C4F04A430 2228C506 024F2A54 C10207C1 01800126 [..("T*O.....&...]
7F3C4F04A440 01800180 01800180 01800180 01800180 [................]
7F3C4F04A450 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04A460 27C5060F 30491C10 0602C102 1A060EC5 [...'..I0........]
7F3C4F04A470 C1020864 01800107 01800180 01800180 [d...............]
7F3C4F04A480 01800180 01800180 06800180 524E1EC5 [..............NR]
7F3C4F04A490 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F04A4A0 C1023049 28C50602 0C1C5B5B 0107C102 [I0.....([[......]
7F3C4F04A4B0 01800180 01800180 01800180 01800180 [................]
7F3C4F04A4C0 01800180 1EC50680 3003524E 012C8001 [........NR.0..,.]
7F3C4F04A4D0 23C20312 27C5060F 30491C10 0602C102 [...#...'..I0....]
7F3C4F04A4E0 3E2F04C5 C102521F 18C20307 0180011B [../>.R..........]
7F3C4F04A4F0 01800180 01800180 01800180 01800180 [................]
7F3C4F04A500 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04A510 27C5060F 30491C10 0602C102 49220CC5 [...'..I0......"I]
7F3C4F04A520 C1020451 19C30408 80016432 80018001 [Q.......2d......]
7F3C4F04A530 80018001 80018001 80018001 C5068001 [................]
7F3C4F04A540 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F04A550 491C1027 02C10230 0905C506 0239453B ['..I0.......;E9.]
7F3C4F04A560 C20302C1 80011E16 80018001 80018001 [................]
7F3C4F04A570 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F04A580 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F04A590 02C10230 3506C506 02335B62 C20303C1 [0......5b[3.....]
7F3C4F04A5A0 C1021E16 01800102 02800180 800102C1 [................]
7F3C4F04A5B0 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
7F3C4F04A5C0 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F04A5D0 C50602C1 04554F2A 03C10207 1816C203 [....*OU.........]
7F3C4F04A5E0 80018001 80018001 80018001 80018001 [................]
7F3C4F04A5F0 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F04A600 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F04A610 0E193023 04C1025E 1816C203 80018001 [#0..^...........]
7F3C4F04A620 80018001 80018001 80018001 80018001 [................]
7F3C4F04A630 4E1EC506 01300352 12012C80 0F23C203 [...NR.0..,....#.]
7F3C4F04A640 1027C506 0230491C C50602C1 135C1E17 [..'..I0.......\.]
7F3C4F04A650 03C10239 80018001 80018001 80018001 [9...............]
7F3C4F04A660 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F04A670 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F04A680 02C10230 5F1CC506 02193F5C C20304C1 [0......_\?......]
7F3C4F04A690 80011816 80018001 80018001 80018001 [................]
7F3C4F04A6A0 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
7F3C4F04A6B0 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
7F3C4F04A6C0 2303C506 020F5E4E C20305C1 80011816 [...#N^..........]
7F3C4F04A6D0 80018001 80018001 80018001 80018001 [................]
7F3C4F04A6E0 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
7F3C4F04A6F0 C5060F23 491C1027 02C10230 600EC506 [#...'..I0......`]
7F3C4F04A700 022B6359 C20307C1 80011816 80018001 [Yc+.............]
7F3C4F04A710 80018001 80018001 80018001 C5068001 [................]
7F3C4F04A720 03524E1E 2C800130 C2031201 C5060F23 [.NR.0..,....#...]
7F3C4F04A730 491C1027 02C10230 0E13C506 02443527 ['..I0.......'5D.]
7F3C4F04A740 C30406C1 01140807 01800180 01800180 [................]
7F3C4F04A750 01800180 01800180 06800180 524E1EC5 [..............NR]
7F3C4F04A760 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F04A770 C1023049 27C50602 3D28540D 0303C102 [I0.....'.T(=....]
7F3C4F04A780 021816C2 800102C1 80018001 0102C102 [................]
7F3C4F04A790 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F04A7A0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04A7B0 0602C102 18221BC5 C1023359 03C40505 [......".Y3......]
7F3C4F04A7C0 012E4F37 01800180 01800180 01800180 [7O..............]
7F3C4F04A7D0 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04A7E0 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04A7F0 20C50602 213F2401 0303C102 011816C2 [... .$?!........]
7F3C4F04A800 01800180 01800180 01800180 01800180 [................]
7F3C4F04A810 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F04A820 060F23C2 1C1027C5 C1023049 20C50602 [.#...'..I0..... ]
7F3C4F04A830 3B0B4302 0107C102 01800180 01800180 [.C.;............]
7F3C4F04A840 01800180 01800180 01800180 1EC50680 [................]
7F3C4F04A850 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F04A860 30491C10 0602C102 4A4D29C5 C1022964 [..I0.....)MJd)..]
7F3C4F04A870 16C20307 01800118 01800180 01800180 [................]
7F3C4F04A880 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F04A890 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04A8A0 0602C102 4D1D26C5 C1025F4B 07C10207 [.....&.MK_......]
7F3C4F04A8B0 80018001 80018001 80018001 80018001 [................]
7F3C4F04A8C0 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F04A8D0 0F23C203 1027C506 0230491C C40502C1 [..#...'..I0.....]
7F3C4F04A8E0 5C034E2F 0106C102 01800180 01800180 [/N.\............]
7F3C4F04A8F0 01800180 01800180 01800180 1EC50680 [................]
7F3C4F04A900 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F04A910 30491C10 0602C102 54110EC5 C1020B29 [..I0.......T)...]
7F3C4F04A920 01800103 01800180 01800180 01800180 [................]
7F3C4F04A930 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04A940 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04A950 1AC50602 0E03324E 0103C102 01800180 [....N2..........]
7F3C4F04A960 01800180 01800180 01800180 01800180 [................]
7F3C4F04A970 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04A980 27C5060F 30491C10 0602C102 36610AC5 [...'..I0......a6]
7F3C4F04A990 C102223F 08C40505 02145A40 800102C1 [?"......@Z......]
7F3C4F04A9A0 80018001 0102C102 01800180 01800180 [................]
7F3C4F04A9B0 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04A9C0 27C5060F 30491C10 0602C102 1F3028C5 [...'..I0.....(0.]
7F3C4F04A9D0 C1024863 16C20303 01800118 01800180 [cH..............]
7F3C4F04A9E0 01800180 01800180 01800180 1EC50680 [................]
7F3C4F04A9F0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F04AA00 30491C10 0602C102 154C1DC5 C102394C [..I0......L.L9..]
7F3C4F04AA10 01800107 01800180 01800180 01800180 [................]
7F3C4F04AA20 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04AA30 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04AA40 13C50602 1F561912 0107C102 01800180 [......V.........]
7F3C4F04AA50 01800180 01800180 01800180 01800180 [................]
7F3C4F04AA60 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04AA70 27C5060F 30491C10 0602C102 330E07C5 [...'..I0.......3]
7F3C4F04AA80 C102561E 02C40506 0409642C 344826C3 [.V......,d...&H4]
7F3C4F04AA90 4B02C203 80018001 4626C304 0180014E [...K......&FN...]
7F3C4F04AAA0 01800180 3CC20380 1EC50637 3003524E [.......<7...NR.0]
7F3C4F04AAB0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04AAC0 0602C102 290315C5 80013812 0C02C405 [.......).8......]
7F3C4F04AAD0 C203493F 80016404 80018001 6404C203 [?I...d.........d]
7F3C4F04AAE0 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F04AAF0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F04AB00 02C10230 0B12C506 02396104 800105C1 [0........a9.....]
7F3C4F04AB10 80018001 80018001 80018001 80018001 [................]
7F3C4F04AB20 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F04AB30 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F04AB40 1B545006 06C10254 0A06C405 C1020C1D [.PT.T...........]
7F3C4F04AB50 01800102 02800180 800102C1 80018001 [................]
7F3C4F04AB60 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F04AB70 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F04AB80 5410260D 0380014A 011A16C2 01800180 [.&.TJ...........]
7F3C4F04AB90 01800180 01800180 01800180 06800180 [................]
7F3C4F04ABA0 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
7F3C4F04ABB0 1C1027C5 C1023049 02C50602 50423830 [.'..I0......08BP]
7F3C4F04ABC0 0309C102 01280DC2 01800180 01800180 [......(.........]
7F3C4F04ABD0 01800180 01800180 06800180 524E1EC5 [..............NR]
7F3C4F04ABE0 80013003 0312012C 060F23C2 1C1027C5 [.0..,....#...'..]
7F3C4F04ABF0 C1023049 19C50602 0D1E4239 0309C102 [I0......9B......]
7F3C4F04AC00 010603C2 01800180 01800180 01800180 [................]
7F3C4F04AC10 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04AC20 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04AC30 18C50502 02644A1A C30406C1 03065F2C [.....Jd.....,_..]
7F3C4F04AC40 015906C2 01800180 06C20380 01800159 [..Y.........Y...]
7F3C4F04AC50 01800180 06800180 524E1EC5 80013003 [..........NR.0..]
7F3C4F04AC60 0312012C 060F23C2 1C1027C5 C1023049 [,....#...'..I0..]
7F3C4F04AC70 26C50602 0B20255F 0506C102 070902C4 [...&_% .........]
7F3C4F04AC80 12C20340 02800125 800106C1 2512C203 [@...%..........%]
7F3C4F04AC90 80018001 80018001 C5068001 03524E1E [.............NR.]
7F3C4F04ACA0 2C800130 C2031201 C5060F23 491C1027 [0..,....#...'..I]
7F3C4F04ACB0 02C10230 3C19C506 02115101 C30407C1 [0......<.Q......]
7F3C4F04ACC0 02472B16 800105C1 80018001 0105C102 [.+G.............]
7F3C4F04ACD0 01800180 01800180 1EC50680 3003524E [............NR.0]
7F3C4F04ACE0 012C8001 23C20312 27C5060F 30491C10 [..,....#...'..I0]
7F3C4F04ACF0 0602C102 285320C5 C1025C3D 2BC10206 [..... S(=\.....+]
7F3C4F04AD00 80018001 80018001 80018001 80018001 [................]
7F3C4F04AD10 80018001 4E1EC506 01300352 12012C80 [.......NR.0..,..]
7F3C4F04AD20 0F23C203 1027C506 0230491C C50602C1 [..#...'..I0.....]
7F3C4F04AD30 1121281E 05C1025A 1716C203 0102C102 [.(!.Z...........]
7F3C4F04AD40 01800180 02C10280 80018001 80018001 [................]
7F3C4F04AD50 C5068001 03524E1E 2C800130 C2031201 [.....NR.0..,....]
7F3C4F04AD60 C5060F23 491C1027 02C10230 1207C506 [#...'..I0.......]
7F3C4F04AD70 012E6364 15C10280 80018001 80018001 [dc..............]
7F3C4F04AD80 80018001 80018001 80018001 4E1EC506 [...............N]
7F3C4F04AD90 01300352 12012C80 0F23C203 1027C506 [R.0..,....#...'.]
7F3C4F04ADA0 0230491C C50602C1 381B010B 03C1021D [.I0........8....]
7F3C4F04ADB0 5223C405 C3044846 0317440E 03593EC2 [..#RFH...D...>Y.]
7F3C4F04ADC0 021903C2 C3044BC1 0139060E 01800180 [.....K....9.....]
7F3C4F04ADD0 04800180 602B0BC3 4E1EC506 01300352 [......+`...NR.0.]
7F3C4F04ADE0 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F04ADF0 C50602C1 47623E1C 02C10230 1206C405 [.....>bG0.......]
7F3C4F04AE00 C2030820 C1024617 06C40516 03255F11 [ ....F......._%.]
7F3C4F04AE10 03180FC2 013117C2 01800180 03800180 [......1.........]
7F3C4F04AE20 062804C2 524E1EC5 80013003 0312012C [..(...NR.0..,...]
7F3C4F04AE30 060F23C2 1C1027C5 C1023049 0DC50602 [.#...'..I0......]
7F3C4F04AE40 051F235E 0406C102 195B27C3 0103C102 [^#.......'[.....]
7F3C4F04AE50 02C10280 C1028001 01800103 01800180 [................]
7F3C4F04AE60 06800180 524E1EC5 80013003 0312012C [......NR.0..,...]
7F3C4F04AE70 060F23C2 1C1027C5 C1023049 24C50602 [.#...'..I0.....$]
7F3C4F04AE80 55210917 0107C102 01800180 01800180 [..!U............]
7F3C4F04AE90 01800180 01800180 01800180 1EC50680 [................]
7F3C4F04AEA0 3003524E 012C8001 23C20312 27C5060F [NR.0..,....#...']
7F3C4F04AEB0 30491C10 0602C102 133004C5 80014156 [..I0......0.VA..]
7F3C4F04AEC0 80018001 80018001 80018001 80018001 [................]
7F3C4F04AED0 80018001 C5068001 03524E1E 2C800130 [.........NR.0..,]
7F3C4F04AEE0 C2031201 C5060F23 491C1027 02C10230 [....#...'..I0...]
7F3C4F04AEF0 2722C506 0131431E 01800180 01800180 [.."'.C1.........]
7F3C4F04AF00 01800180 01800180 01800180 06800180 [................]
7F3C4F04AF10 524E1EC5 80013003 0312012C 060F23C2 [..NR.0..,....#..]
7F3C4F04AF20 1C1027C5 C1023049 03C50602 24473E34 [.'..I0......4>G$]
7F3C4F04AF30 80018001 80018001 80018001 80018001 [................]
7F3C4F04AF40 80018001 80018001 4E1EC506 01300352 [...........NR.0.]
7F3C4F04AF50 12012C80 0F23C203 1027C506 0230491C [.,....#...'..I0.]
7F3C4F04AF60 C50602C1 5256541F 0180011A 01800180 [.....TVR........]
7F3C4F04AF70 01800180 01800180 01800180 01800180 [................]
7F3C4F04AF80 1EC50680 3003524E 012C8001 23C20312 [....NR.0..,....#]
7F3C4F04AF90 012C060F 78780A03 78787878 78787878 [..,...xxxxxxxxxx]
7F3C4F04AFA0 00700028 000C0101 00010080 00010000 [(.p.............]
7F3C4F04AFB0 DE240000 48140017 000E0090 78010A00 [..$....H.......x]
7F3C4F04AFC0 78787878 78787878 70003278 0C020100 [xxxxxxxxx2.p....]
7F3C4F04AFD0 02008080 01000000 24000000 1E0018DE [...........$....]
7F3C4F04AFE0 18009048 01140000 78007800 78007800 [H........x.x.x.x]
7F3C4F04AFF0 78007800 78007800 78007800 83CF0601 [.x.x.x.x.x.x....]
Block scn: 0x2a883cf
Block header dump: 0x0000030f
Object id on Block? Y
seg/obj: 0x24c75 csc: 0x0000000002a883cd itc: 2 flg: E- typ: 1 - DATA
brn: 0 bdba: 0x308 ver: 0x01 opc: 0
inc: 0 exflg: 0
Itl Xid Uba Flag Lck Scn/Fsc
0x01 0x0002.000.00004254 0x00000273.116a.04 --U- 1 fsc 0x0000.02a883cf
0x02 0x0000.000.00000000 0x00000000.0000.00 ---- 0 fsc 0x0000.00000000
bdba: 0x0000030f type: 0x06 SAGE: 0
data_block_dump,data header at 0x7f3c4f049064
===============
tsiz: 0x1f98
hsiz: 0x14
pbl: 0x7f3c4f049064
76543210
flag=--------
ntab=1
nrow=1
frre=-1
fsbo=0x14
fseo=0x1f2e
avsp=0x1f1a
tosp=0x1f1a
0xe:pti[0] nrow=1 offs=0
0x12:pri[0] offs=0x1f2e
block_row_dump:
tab 0, row 0, @0x1f2e
tl: 106 fb: --H-FL-- lb: 0x1 cc: 3
col 0: [10] 78 78 78 78 78 78 78 78 78 78
col 1: [40]
00 70 00 01 01 0c 00 80 00 01 00 00 00 01 00 00 00 24 de 17 00 14 48 90 00
0e 00 00 0a 01 78 78 78 78 78 78 78 78 78 78
LOB
Locator:
Length: 112(40)
Version: 1
Byte Length: 1
LobID: 00.00.00.01.00.00.00.24.de.17
Flags[ 0x01 0x0c 0x00 0x80 ]:
Type: BLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: ReadWrite
SecureFile Header:
Length: 20
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:14
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 10
VER: 1
INLINE DATA (10):
78 78 78 78 78 78 78 78 78 78
col 2: [50]
00 70 00 01 02 0c 80 80 00 02 00 00 00 01 00 00 00 24 de 18 00 1e 48 90 00
18 00 00 14 01 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
LOB
Locator:
Length: 112(50)
Version: 1
Byte Length: 2
LobID: 00.00.00.01.00.00.00.24.de.18
Flags[ 0x02 0x0c 0x80 0x80 ]:
Type: CLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: VaringWidthReadWrite
SecureFile Header:
Length: 30
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:24
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 20
VER: 1
INLINE DATA (20):
00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
00 78 00 78
end_of_block_dump
End dump data blocks tsn: 7 file#: 16 minblk 783 maxblk 783The interesting bits are these:
block_row_dump:
tab 0, row 0, @0x1f2e
tl: 106 fb: --H-FL-- lb: 0x1 cc: 3
col 0: [10] 78 78 78 78 78 78 78 78 78 78
col 1: [40]
00 70 00 01 01 0c 00 80 00 01 00 00 00 01 00 00 00 24 de 17 00 14 48 90 00
0e 00 00 0a 01 78 78 78 78 78 78 78 78 78 78
LOB
Locator:
Length: 112(40)
Version: 1
Byte Length: 1
LobID: 00.00.00.01.00.00.00.24.de.17
Flags[ 0x01 0x0c 0x00 0x80 ]:
Type: BLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: ReadWrite
SecureFile Header:
Length: 20
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:14
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 10
VER: 1
INLINE DATA (10):
78 78 78 78 78 78 78 78 78 78
col 2: [50]
00 70 00 01 02 0c 80 80 00 02 00 00 00 01 00 00 00 24 de 18 00 1e 48 90 00
18 00 00 14 01 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
LOB
Locator:
Length: 112(50)
Version: 1
Byte Length: 2
LobID: 00.00.00.01.00.00.00.24.de.18
Flags[ 0x02 0x0c 0x80 0x80 ]:
Type: CLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: VaringWidthReadWrite
SecureFile Header:
Length: 30
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:24
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 20
VER: 1
INLINE DATA (20):
00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
00 78 00 78
end_of_block_dump
- Line 4 shows that column 0 contains 10 bytes of the hex value
78(hex 78 = decimal 120 = “Lowercase x”:col 0: [10] 78 78 78 78 78 78 78 78 78 78 - Lines 5-7 show that column 1 contains 40 bytes:
col 1: [40] 00 70 00 01 01 0c 00 80 00 01 00 00 00 01 00 00 00 24 de 17 00 14 48 90 00 0e 00 00 0a 01 78 78 78 78 78 78 78 78 78 78- Line 8 tells us that the type of the column is LOB
- Line 12 confirms that the byte length is 1 (not 2)
- Line 15 tells us that the type of the LOB is
BLOB(notCLOB) - Lines 30-31 show the data to be 10 occurrences of the hex value
78, the same 10xas in theVARCHAR2column:INLINE DATA (10): 78 78 78 78 78 78 78 78 78 78
- Lines 33-35 show that column 2 contains 50 bytes (10 bytes more than column one):
col 2: [50] 00 70 00 01 02 0c 80 80 00 02 00 00 00 01 00 00 00 24 de 18 00 1e 48 90 00 18 00 00 14 01 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78- Line 36 tells us that the type of the column is LOB
- Line 40 confirms that the byte length is 2 (2 bytes per character)
- Line 43 tells us that we are dealing with a
CLOB - Lines 58-60 show the data to be 20 bytes of the 2-byte pattern
00 78:INLINE DATA (20): 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78 00 78
What we can conclude from the block dump is that extended VARCHAR2s are stored as BLOBs, not CLOBs. Because BLOBs just store bytes as they are, we can see that the same values are stored as the VARCHAR2 column. Meanwhile, the CLOB column stores the same data in a 2-byte fixed-width character set (UCS2 / AL32UTF16).
Note: The usage of the LOB layer to store a large number of bytes is nothing new nor special to extended VARCHAR2. It is used because the LOB facility is purpose-built to gather and maintain a dynamic number of database blocks, making them a cohesive unit. The same mechanism is used for these other data types:
VECTORJSONXMLType
Why do CLOBs use a 2-byte fixed-width character set anyway?
The reason for that is to enable fast random access of offset-based reads. Imagine a scenario where one would like to read 10 characters from the offset of 10,895,324. With a variable-width character set, you cannot just read 10 bytes from byte 10,895,324 onwards because you may have used one or more bytes for a character. Hence, you would always have to read from the beginning and determine the byte length of all characters to know where the offset starts. At this stage, you no longer benefit from offsets, as you always have to start from the beginning. That’s obviously highly inefficient, the larger the data inside the LOB gets. But if you have a fixed-width character set, you always know exactly where to start to read from because a given character will always take up the same number of bytes as any other character. In the example just stated, wanting to read from offset 10,895,324, you can always start reading from byte 21,790,648 (10,895,324 * 2) and read 20 bytes from there, because every character is 2 bytes long.
Are CLOB characters always converted?
It is another general misconception that CLOB values are always converted to the 2-byte fixed-width UCS2 / AL32UTF16 character set. This is only the case if the database itself is running in a variable-width character set. However, if the database is running in a fixed-width character set, no conversion takes place as it isn’t required.
Here is the proof that not all single-byte character sets are subject to that 2-byte character set conversion. I have another database running in WE8ISO8859P15 – a single-byte fixed-width character set:
SQL> SELECT * FROM nls_database_parameters WHERE parameter='NLS_CHARACTERSET';
PARAMETER VALUE
---------------- -------------
NLS_CHARACTERSET WE8ISO8859P15
I have again a table test this time with 2 CLOBs, just to show inline (c1) and out-of-line (c2) storage and that they behave the same:
SQL> create tablespace test datafile '/opt/oracle/oradata/FREE/FREEPDB1/test.dbf' size 10m;
Tablespace created.
SQL> select file# from v$datafile where name = '/opt/oracle/oradata/FREE/FREEPDB1/test.dbf';
FILE#
----------
18
SQL> create table test (c1 clob, c2 clob)
2 tablespace test
3 lob (c1) store as (tablespace test)
4 lob (c2) store as (tablespace test);
Table created.
SQL> insert into test values (rpad('x',20,'x'), rpad('x',5000,'x'));
1 row created.
SQL> commit;
Commit complete.
SQL> select DBMS_ROWID.ROWID_BLOCK_NUMBER(rowid) from test;
DBMS_ROWID.ROWID_BLOCK_NUMBER(ROWID)
------------------------------------
780
SQL> alter system dump datafile 18 block 780;
System altered.
The block dump proves that the inline WE8ISO8859P15 value remains single-byte:
block_row_dump:
tab 0, row 0, @0x1f3b
tl: 93 fb: --H-FL-- lb: 0x1 cc: 2
col 0: [50]
00 70 00 01 02 0c 00 80 00 01 00 00 00 01 00 00 00 0e bd 71 00 1e 48 90 00
18 00 00 14 01 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78
LOB
Locator:
Length: 112(50)
Version: 1
Byte Length: 1
LobID: 00.00.00.01.00.00.00.0e.bd.71
Flags[ 0x02 0x0c 0x00 0x80 ]:
Type: CLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: ReadWrite
SecureFile Header:
Length: 30
Old Flag: 0x48 [ DataInRow SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:24
INODE:
FLG0: 0x00 [ INLINE LENNB: 1 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 20
VER: 1
INLINE DATA (20):
78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78
78 78 78 78
col 1: [38]
00 70 00 01 02 0c 00 80 00 01 00 00 00 01 00 00 00 0e bd 72 00 12 40 90 00
0c 21 00 0f a0 01 00 01 00 00 03 52 01
LOB
Locator:
Length: 112(38)
Version: 1
Byte Length: 1
LobID: 00.00.00.01.00.00.00.0e.bd.72
Flags[ 0x02 0x0c 0x00 0x80 ]:
Type: CLOB
Storage: SecureFile
Characterset Format: IMPLICIT
Options: ReadWrite
SecureFile Header:
Length: 18
Old Flag: 0x40 [ SecureFile ]
Flag 0: 0x90 [ INODE Valid ]
Layers:
Lengths Array: INODE:12
INODE:
FLG0: 0x21 [ HEADLESS LENNB: 2 ]
FLG1: 0x00 [ VERNB: 1 ]
LEN: 4000
VER: 1
LOBMAP:
EXT 0 - FLG:0x01 [ELENNB: 2 ]
DBA: 0x00000352 #BLKS: 1
end_of_block_dump
And the out-of-line CLOB block dump confirms the same, the values remain single-byte length:
SQL> -- Use 'xx' to convert hex number, convert 0352 hex to decimal
SQL> select to_number('0352','xxxx');
TO_NUMBER('0352','XXXX')
------------------------
850
Session altered.
SQL> alter system dump datafile 18 block 850;
System altered.
Block header dump: 0x00000352
Object id on Block? Y
seg/obj: 0x11958 csc: 0x00000000002020a5 itc: 1 flg: E- typ: 5 - LOCAL LOBS
fsl: 0 fnx: 0xffffffff ver: 0x01
Itl Xid Uba Flag Lck Scn/Fsc
0x01 0x0007.016.00000236 0x00000000.0000.00 -B-- 0 fsc 0x0000.00000000
========
bdba [0x00000352]
kdlich [0x7f7b0f20f04c 56]
flg0 0x20 [ver=0 typ=data lock=n]
flg1 0x00
scn 0x00000000002020a5 [0x0000.8000.002020a5]
lid 000000010000000ebd72
spare 0x00000000
kdlidh [0x7f7b0f20f064 24]
flg2 0x00 [ver=0 lid=short-rowid hash=n cmap=n pfill=n]
flg3 0x00
pskip 0
sskip 0
hash 0000000000000000000000000000000000000000
hwm 4000
spr 0
data [0x7f7b0f20f080 52 8060]
78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78
78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78
78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78 78
...
...
Extended VARCHAR2s, although stored as (B)LOBs, are not just tiny CLOBs under the covers. They are VARCHAR2 types that leverage the LOB storage facility to manage multiple database blocks as a cohesive unit. Furthermore, CLOBs do only go through character set conversion if the database character set is a variable-width character set. The mechanism isn’t bad or faulty, but done to provide retrieval capabilities of arbitrary parts of the CLOB with consistent performance.
Related — the implementation of EXTENDED VARCHAR2s is odd. Oracle makes it seem like there is no LOB involved. The reason I say that is — if you create the column as > 4000, it’s created as a LOB. But if you create it as <=4000 and then change the column width, it's truly an inline "lob". which means you can easily get chained rows too. 🙂
drop table v2 purge;
create table v2 (id number, descr varchar2(10000));
insert into v2 values(1,rpad('x',10000,'x'));
commit;
select object_name,object_type
from user_objects
where object_type in ('TABLE','INDEX');
OBJECT_NAME OBJECT_TYPE
———————————– ———————–
SYS_IL0225332258C00002$$ INDEX
V2 TABLE
But…
drop table v2 purge;
create table v2 (id number, descr varchar2(4000));
— keep inline
alter table v2 modify (descr varchar2(10000));
insert into v2 values(1,rpad('x',10000,'x'));
commit;
select object_name,object_type
from user_objects
where object_type in ('TABLE','INDEX');
OBJECT_NAME OBJECT_TYPE
———————————– ———————–
V2 TABLE
Clarification — there is an actual LOB segment in the first example:
SYS_IL0225332275C00002$$ LOBINDEX ASSM 65536
V2 TABLE ASSM 65536
SYS_LOB0225332275C00002$$ LOBSEGMENT SECUREFILE 1245184
But in the “inline” example, it’s all in the table segment.
V2 TABLE ASSM 196608
